Schneider Electric Acti9 STI fuse-disconnector, rated 2 A. Acti9 - fuse-disconnector STI - 3 poles + N - 25 A - for fuse 10.3 x 38 mm.
Acti9 - fuse-disconnector STI - 3 poles + N - 25 A - for fuse 10.3 x 38 mm. Genuine Schneider Electric product supplied by United Force.
| Range | Acti9 |
|---|---|
| Product name | Acti9 STI |
| Product or component type | Fuse-disconnector |
| Device short name | STI |
| Poles description | 3P + N |
| [In] rated current | 2 A · 4 A · 6 A · 10 A · 16 A · 20 A · 25 A |
| Fuse type | aM fuse · gG fuse |
| Fuse size | 10.3 x 38 mm |
| [Ue] rated operational voltage | 500 V AC |
| [Ui] rated insulation voltage | 500 V AC 50/60 Hz |
| Mounting mode | Clip-on |
| Mounting support | DIN rail |
| 9 mm pitches | 6 |
| Height | 81 mm |
| Width | 54 mm |
| Depth | 75 mm |
| Colour | White |
| Connections - terminals | Screw clamp terminals1 cable(s) 0.75…10 mm² rigid · Screw clamp terminals1 cable(s) 0.5…6 mm² flexible · Screw clamp terminals2 cable(s) 0.75…4 mm² rigid · Screw clamp terminals2 cable(s) 0.5…6 mm² flexible |
| Wire stripping length | 12 mm |
| Tightening torque | 2 N.m |
| Standards | IEC 60269-1/2 · IEC EN 60947-3 |
| IP degree of protection | IP20 |
| Pollution degree | 3 |
| Ambient air temperature for operation | -20…60 °C |
| Ambient air temperature for storage | -40…80 °C |
| Unit Type of Package 2 | BB1 |
| Number of Units in Package 2 | 4 |
| Package 2 Height | 8.500 cm |
| Package 2 Width | 9.300 cm |
| Package 2 Length | 22.200 cm |
| Package 2 Weight | 786.000 g |
| Unit Type of Package 3 | S03 |
| Number of Units in Package 3 | 48 |
| Package 3 Height | 30.000 cm |
| Package 3 Width | 30.000 cm |
| Package 3 Length | 40.000 cm |
| Package 3 Weight | 9.917 kg |
| Warranty (in months) | 18 |
