Schneider Electric actuator. SpaceLogic M310 Actuator, Non-Spring Return, 24Vac/dc, 300N, IP54.
SpaceLogic M310 Actuator, Non-Spring Return, 24Vac/dc, 300N, IP54. Genuine Schneider Electric product supplied by United Force.
| Actuator product range | SpaceLogic |
|---|---|
| Product or component type | Actuator |
| Actuator type | Electric |
| Actuator product series | M310 |
| Actuator model | M310 |
| Product destination | globe valve |
| Actuator | Linear |
| Motor type | Brushless DC motor |
| Control type | Automatic reset |
| Switch function | 2 SPDT (optional) |
| rated supply voltage | 24 V AC/DC |
| Analogue input range | 0...10 V DC |
| Feedback signal | 2...10 V DC |
| Transformer rated power in VA | 30 VA |
| Power consumption in VA | 6 VA AC |
| Hold-in power consumption in VA | 6 VA AC |
| Power loss return | Non-spring return |
| Control signal | Floating · Proportional/modulating |
| Stroke length | 9…32 mm |
| Stroke auto calibration | True |
| Electrical insulation class | Class II |
| Force N | 300 N |
| Force lbf | 68 lbf |
| Position indicator | Stroke indicator on yoke |
| Conduit connection | 3 x M20 · Gland for 6-9 mm O/D cable |
| Leads and connections | Terminal block |
| Stroke running time | 15 s |
| IP degree of protection | IP54 |
| Duty cycle | 20 % |
| Ambient air temperature for operation | -10…50 °C |
| Relative humidity | 0…90 % |
| Ambient air temperature for storage | -10…50 °C |
| Targeted region | Europe · Asia Pacific. · Australia. |
| Warranty (in months) | 18 |
