Schneider Electric actuator. MV15B-230 Electric Globe Valve Actuator, 3-Wire Floating, 230Vac, 1500N, Linear, IP55.
MV15B-230 Electric Globe Valve Actuator, 3-Wire Floating, 230Vac, 1500N, Linear, IP55. Genuine Schneider Electric product supplied by United Force.
| Actuator product range | SpaceLogic |
|---|---|
| Product or component type | Actuator |
| Actuator type | Electric |
| Actuator product series | MV15B |
| Actuator model | MV15B |
| Product destination | globe valve |
| Actuator | Linear |
| Motor type | Brushless DC motor |
| Control type | Automatic reset |
| Switch function | 2 SPDT (optional) |
| rated supply voltage | 230 V AC |
| Transformer rated power in VA | 15 VA |
| Power consumption in VA | 12 VA AC |
| Hold-in power consumption in VA | 12 VA AC |
| Power loss return | Non-spring return |
| Control signal | Floating |
| Stroke length | 9…52 mm |
| Stroke auto calibration | True |
| Electrical insulation class | Class II |
| Force N | 1500 N |
| Force lbf | 337 lbf |
| Position indicator | Stroke indicator on yoke |
| Conduit connection | 2 x 20 mm conduit hole |
| Leads and connections | Terminal block |
| Stroke running time | 132 s |
| IP degree of protection | IP40 |
| Ambient air temperature for operation | -15…50 °C |
| Relative humidity | 0…90 % |
| Ambient air temperature for storage | -10…50 °C |
| Targeted region | Europe · Asia Pacific. · Australia. |
| Warranty (in months) | 18 |
