Schneider Electric time delay relay. MN delay unit, MasterPact NT/NW, ComPacT NS, adjustable time delay 0.5s/3s, 200/250VDC, 200/250VAC 50/60Hz, spare part.
MN delay unit, MasterPact NT/NW, ComPacT NS, adjustable time delay 0.5s/3s, 200/250VDC, 200/250VAC 50/60Hz, spare part. Genuine Schneider Electric product supplied by United Force.
| Device short name | MN delay unit |
|---|---|
| Product or component type | Time delay relay |
| Device application | Control |
| Range compatibility | Masterpact MasterPact NT · Masterpact MasterPact NW · ComPact ComPact NSX · ComPact ComPact NS630b...1600 · ComPact ComPact NS1600b...3200 · PowerPact PowerPact Multistandard · ComPact ComPact NSXm · ComPact ComPact NSX DC · Masterpact MasterPact NW UL 489 · Masterpact MasterPact NT UL 489 · Masterpact MasterPact NW DC |
| Voltage release type | Undervoltage release |
| [Uc] control circuit voltage | 200...250 V AC 50/60 Hz · 200...250 V DC |
| Impulse duration | 200 ms |
| Time delay range | 0.5...3 s |
| Threshold tripping voltage | 0.35...0.7 Un open · 0.85 Un close |
| Supply holding power | 4.5 VA |
| Supply inrush power | 200 VA |
| Mounting mode | External mounting |
| Response time | 0.5 s · 1 s · 1.5 s · 3 s |
| Accessory / separate part category | Spare part for Compact NS630b...1600 · Spare part for Compact NS1600b...3200 |
| Unit Type of Package 2 | S03 |
| Number of Units in Package 2 | 36 |
| Package 2 Height | 30.000 cm |
| Package 2 Width | 30.000 cm |
| Package 2 Length | 40.000 cm |
| Package 2 Weight | 6.678 kg |
| Warranty (in months) | 18 |
