Schneider Electric MasterPact time delay auxiliary. MN delay unit, MasterPact MTZ, adjustable time delay 0.5s to 3s, 48/60VDC, 48/60VAC 50/60Hz, spare part.
MN delay unit, MasterPact MTZ, adjustable time delay 0.5s to 3s, 48/60VDC, 48/60VAC 50/60Hz, spare part. Genuine Schneider Electric product supplied by United Force.
| Range | MasterPact |
|---|---|
| Device short name | MN delay unit |
| Product or component type | Time delay auxiliary |
| Device application | Control |
| Range compatibility | Masterpact MasterPact MTZ1 circuit breaker · Masterpact MasterPact MTZ2 circuit breaker · Masterpact MasterPact MTZ3 circuit breaker |
| Voltage release type | Instantaneous |
| Impulse duration | 200 ms |
| Time delay range | 0.5...3 s |
| [Uc] control circuit voltage | 48...60 V AC 50/60 Hz · 48...60 V DC |
| Threshold tripping voltage | 0.35...0.7 Un open · 0.85 Un close |
| Supply holding power | 4.5 VA |
| Supply inrush power | 200 VA |
| Response time | 0.5 s · 0.9 s · 1.5 s · 3 s |
| Offer type | Spare part |
| Provided equipment | 1 instruction sheet |
| Unit Type of Package 2 | S03 |
| Number of Units in Package 2 | 30 |
| Package 2 Height | 30.0 cm |
| Package 2 Width | 30.0 cm |
| Package 2 Length | 40.0 cm |
| Package 2 Weight | 6.24 kg |
| Warranty (in months) | 18 |
