| الفئة | TeSys |
|---|
| اسم المنتج | TeSys T |
|---|
| الاسم المختصر للجهاز | LTMR |
|---|
| نوع المنتج أو المكوّن | متحكم المحرك |
|---|
| استخدام الجهاز | مراقبة المعدات والتحكم بها |
|---|
| تيار القياس | 1.35…27 A |
|---|
| [Us] جهد التغذية المقنّن | 100...240 V AC 50/60 Hz |
|---|
| استهلاك التيار | 8...62.8 mA |
|---|
| حدود جهد التغذية | 93.5…264 V AC |
|---|
| بروتوكول منفذ الاتصال | Profibus DP |
|---|
| نوع الناقل | Profibus DP polarised 2-wire RS485 interface, addressing 1...125, transmission rate 9.6 kbit/s...12 Mbit/s, SUB-D 9 with 2 shielded twisted pairs, type A · Profibus DP polarised 2-wire RS485 interface, addressing 1...125, transmission rate 9.6 kbit/s...12 Mbit/s, terminal block with 2 shielded twisted pairs, type A |
|---|
| [Ui] جهد العزل المقنّن | 690 V مطابق لـ EN/IEC 60947-1 · 690 V مطابق لـ CSA C22.2 No 14 · 690 V مطابق لـ UL 508 |
|---|
| [Uimp] جهد تحمّل النبضة المقنّن | 4 kV supply, inputs and outputs مطابق لـ EN/IEC 60947-4-1 · 6 kV current or voltage measurement circuit مطابق لـ EN/IEC 60947-4-1 · 0.8 kV communication circuit مطابق لـ EN/IEC 60947-4-1 |
|---|
| تحمّل القصر | 100 kA مطابق لـ EN/IEC 60947-4-1 |
|---|
| تقنين المصهر المرافق | 4 A gG for output · 0.5 A gG for control circuit |
|---|
| نوع الحماية | Load fluctuation · Thermal protection · Locked rotor · Reverse polarity protection · عدم اتزان الأطوار · Earth-leakage protection · حمل زائد (long time) · Thermal overload protection · حمل زائد · Phase failure · Power factor variation |
|---|
| نوع تشخيص الشبكة والآلة | Phase fault and earth fault trip counters · Trip history information · Trip context information · Motor control command recording · Running hours counter/operating time · Waiting time after overload tripping · Remaining operating time before overload tripping · Fault recording · Starting current and time · Event recording |
|---|
| عدد المداخل المنطقية | 6 |
|---|
| تيار الدخل | 3.1 mA at 100 V · 7.5 mA at 240 V |
|---|
| التيار المضمون للحالة 0 | Logic input: 0...40 V and <= 15 mA for 25 ms |
|---|
| التيار المضمون للحالة 1 | Logic input: 79...264 V and >= 2 mA for 25 ms |
|---|
| أقصى تردد تبديل للخرج | 2 Hz |
|---|
| تيار الحمل | 5 A at 250 V AC for logic output · 5 A at 30 V DC for logic output |
|---|
| القدرة المسموح بها | 480 VA (AC-15), Ie = 2 A, 500000 cycles (output) · 30 W (DC-13), Ie = 1.25 A, 500000 cycles (output) |
|---|
| أقصى معدل تشغيل | 1800 cyc/h |
|---|
| نوع التلامسات وتركيبها | 1 NO + 1 NC fault signal · 3 NO |
|---|
| نوع القياس | Average current Iavg · درجة الحرارة · Earth-fault current · Phase current I1, I2, I3 RMS · Imbalance current |
|---|
| دقة القياس | 5...15 % earth fault current internal measurement · 1 % voltage (100...830 V) · 3 % power factor · 5 % earth fault current external measurement · +/- 30 min/year internal clock · 0,02 temperature · 1 % current · 5 % active and reactive power |
|---|
| فئة الجهد الزائد | III |
|---|
| مسافة التوصيل | 5.08 mm |
|---|
| التوصيلات - الأطراف | دارة التحكم: connector 1 cable(s) 0.25…2.5 mm² (24 AWG...14 AWG) flexible with cable end · دارة التحكم: connector 1 cable(s) 0.2…2.5 mm² (24 AWG...14 AWG) flexible without cable end · دارة التحكم: connector 1 cable(s) 0.25…2.5 mm² (24 AWG...14 AWG) flexible without cable end · دارة التحكم: connector 1 cable(s) 0.2…2.5 mm² (24 AWG...14 AWG) solid without cable end · دارة التحكم: connector 2 cable(s) 0.2…1 mm² (24 AWG...14 AWG) flexible with cable end · دارة التحكم: connector 2 cable(s) 0.2…1.5 mm² (24 AWG...14 AWG) flexible without cable end · دارة التحكم: connector 2 cable(s) 0.5…1.5 mm² (24 AWG...14 AWG) flexible without cable end · دارة التحكم: connector 2 cable(s) 0.2…1 mm² (24 AWG...14 AWG) solid without cable end |
|---|
| عزم الربط | دارة التحكم: 0.5…0.6 N.m flat screwdriver 3 mm |
|---|
| درجة التلوّث | 3 |
|---|
| التوافق الكهرومغناطيسي | Electrostatic discharge, 3, 8 kV air, 6 kV contact, مطابق لـ EN/IEC 61000-4-2 · Radiated RF fields, 3, 10 V/m, مطابق لـ EN/IEC 61000-4-3 · Fast transients immunity test (other circuits), level 3, 2 kV, مطابق لـ EN/IEC 61000-4-4 · Fast transients immunity test (on supply and relay outputs), level 4, 4 kV, مطابق لـ EN/IEC 61000-4-4 · Voltage dips and interruptions immunity test, 70 %, 500 ms, مطابق لـ EN/IEC 61000-4-11 · Conducted RF disturbances, 10 V, مطابق لـ EN/IEC 61000-4-6 · مجس درجة الحرارة: surges (serial mode), 0.5 kV, مطابق لـ EN/IEC 61000-4-5 · مجس درجة الحرارة: surges (common mode), 1 kV, مطابق لـ EN/IEC 61000-4-5 · دارة التحكم: surges (serial mode), 1 kV, مطابق لـ EN/IEC 61000-4-5 · اتصال: surges (common mode), 2 kV, مطابق لـ EN/IEC 61000-4-5 · Relay outputs and supply: surges (serial mode), 2 kV, مطابق لـ EN/IEC 61000-4-5 · Relay outputs and supply: surges (common mode), 4 kV, مطابق لـ EN/IEC 61000-4-5 · دارة التحكم: surges (common mode), 2 kV, مطابق لـ EN/IEC 61000-4-5 |
|---|
| العرض | 91 mm |
|---|
| الارتفاع | 61 mm |
|---|
| العمق | 122.5 mm |
|---|
| وزن المنتج | 0.53 kg |
|---|
| خدمات الويب | خادم ويب |
|---|
| رمز التوافق | LTMR |
|---|
| المعايير | EN 60947-4-1 · UL 508 · IACS E10 · CSA C22.2 No 14 · IEC 60947-4-1 |
|---|
| شهادات المنتج | BV · CSA · CCC · EAC · NOM · KERI · ABS · RMRoS · LROS (Lloyds register of shipping) · UL · RINA · DNV · GL · C-Tick · ATEX |
|---|
| المعالجة الوقائية | 12 x 24 hour cycles مطابق لـ EN/IEC 60068-2-30 · 48 h مطابق لـ EN/IEC 60070-2-11 · TH مطابق لـ EN/IEC 60068 |
|---|
| مقاومة الحريق | 650 °C مطابق لـ EN/IEC 60695-2-12 · 960 °C مطابق لـ UL 94 |
|---|
| حرارة الهواء المحيط أثناء التشغيل | -20…60 °C |
|---|
