Schneider Electric TeSys CAD control relay, rated 10 A. Control relay, TeSys Deca, 3NO+2NC, 0 to 690V, 24VDC standard coil, Lugs-ring terminals.
Control relay, TeSys Deca, 3NO+2NC, 0 to 690V, 24VDC standard coil, Lugs-ring terminals. Genuine Schneider Electric product supplied by United Force.
| Range | TeSys · TeSys Deca |
|---|---|
| Product name | TeSys CAD |
| Product or component type | Control relay |
| Device short name | CAD |
| Contactor application | Control circuit |
| Utilisation category | AC-14 · AC-15 · DC-13 |
| Pole contact composition | 3 NO + 2 NC |
| [Ue] rated operational voltage | <= 690 V AC 25...400 Hz |
| Control circuit type | DC standard |
| [Uc] control circuit voltage | 24 V DC |
| [Uimp] rated impulse withstand voltage | 6 kV conforming to IEC 60947 |
| [Ith] conventional free air thermal current | 10 A (at 60 °C) |
| Irms rated making capacity | 140 A AC conforming to IEC 60947-5-1 · 250 A DC conforming to IEC 60947-5-1 |
| [Icw] rated short-time withstand current | 100 A - 1 s · 120 A - 500 ms · 140 A - 100 ms |
| Associated fuse rating | 10 A gG conforming to IEC 60947-5-1 |
| [Ui] rated insulation voltage | 600 V UL certified · 600 V CSA certified · 690 V conforming to IEC 60947-5-1 |
| Mounting support | Plate · Rail |
| Connections - terminals | Lugs-ring terminals (external diameter: 8 mm) |
| Control circuit voltage limits | 0.1...0.25 Uc (-40…70 °C):drop-out DC · 0.7...1.25 Uc (-40…60 °C):operational DC · 1...1.25 Uc (60…70 °C):operational DC |
| Operating time | 53...72 ms coil energisation and NO closing · 16...24 ms coil de-energisation and NO opening · 47...63 ms coil energisation and NC opening · 15...25 ms coil de-energisation and NC closing |
| Mechanical durability | 30 Mcycles |
| Maximum operating rate | 180 cyc/mn |
| Time constant | 28 ms |
| Inrush power in W | 5.4 W (at 20 °C) |
| Hold-in power consumption in W | 5.4 W at 20 °C |
| Minimum switching voltage | 17 V |
| Minimum switching current | 5 mA |
| Non-overlap time | 1.5 ms on energisation between NC and NO contact · 1.5 ms on de-energisation between NC and NO contact |
| Insulation resistance | > 10 MOhm |
| Mechanical robustness | Shocks control relay open: 10 Gn for 11 ms conforming to IEC 60068-2-27 · Shocks control relay closed: 15 Gn for 11 ms conforming to IEC 60068-2-27 · Vibrations control relay open: 2 Gn, 5...300 Hz conforming to IEC 60068-2-6 · Vibrations control relay closed: 4 Gn, 5...300 Hz conforming to IEC 60068-2-6 |
| Height | 77 mm |
| Width | 45 mm |
| Depth | 93 mm |
| Product weight | 0.58 kg |
| Standards | EN/IEC 60947-5-1 · GB/T 14048.5 · UL 60947-5-1 · CSA C22.2 No 60947-5-1 · JIS C8201-5-1 |
| Product certifications | CB · CCC · UL · CSA · EAC · CE · UKCA |
| IP degree of protection | IP2X front face conforming to VDE 0106 |
| Protective treatment | TH conforming to IEC 60068 |
| Ambient air temperature for operation | -40…60 °C · 60…70 °C with derating |
| Ambient air temperature for storage | -60…80 °C |
| Operating altitude | 0...3000 m |
| Unit Type of Package 2 | S02 |
| Number of Units in Package 2 | 16 |
| Package 2 Height | 15.000 cm |
| Package 2 Width | 30.000 cm |
