Schneider Electric bos internal bus extension kit. bus extension kit, Modicon STB, BOS internal.
bus extension kit, Modicon STB, BOS internal. Genuine Schneider Electric product supplied by United Force.
| Range of product | Modicon STB distributed I/O solution |
|---|---|
| Product or component type | BOS internal bus extension kit |
| Kit composition | STBXBE1300 BOS module · STBXTS2120, 2-terminal spring clamp connector · STBXBA2300 size 2 base · STBXTS1120, 2-terminal screw type connector |
| Product compatibility | Standard STB modules |
| Mounting location | Beginning of extension segment |
| [Us] rated supply voltage | 24 V |
| Supply circuit type | DC |
| Supply voltage limits | 19.2…30 V |
| Input current | 400 mA |
| Output voltage | 5.25 V +/- 0.21 % logic bus |
| Output voltage type | DC |
| Power supply output current | 1.2 A |
| Electrical connection | 2 pins for removable connector for power supply · Firewire for interface |
| DC supply voltage | 24 V |
| Height | 120 mm |
| Width | 18.4 mm |
| Depth | 70 mm |
| Marking | CE |
| Overvoltage category | II |
| IP degree of protection | IP20 conforming to IEC 61131-2 class 1 |
| Product certifications | FM Class 1 Division 2 · UL · CSA |
| Ambient air temperature for storage | -40…85 °C |
| Relative humidity | 95 % at 60 °C without condensation |
| Operating altitude | <= 2000 m |
| Pollution degree | 2 conforming to IEC 60664-1 |
| Vibration resistance | 3 gn at 58…150 Hz on 35 x 7.5 mm symmetrical DIN rail · 5 gn at 58…150 Hz on 35 x 15 mm symmetrical DIN rail · +/-0.35 mm at 10…58 Hz |
| Shock resistance | 30 gn for 11 ms conforming to IEC 88 reference 2-27 |
| Electromagnetic compatibility | Immunity to electromagnetic interference conforming to IEC 61131-2 |
| Unit Type of Package 2 | S02 |
| Number of Units in Package 2 | 42 |
| Package 2 Height | 15.000 cm |
| Package 2 Width | 30.000 cm |
| Package 2 Length | 40.000 cm |
| Package 2 Weight | 5.670 kg |
| Warranty (in months) | 18 |
