Schneider Electric Acti9 C120 miniature circuit-breaker, rated 63 A. Miniature circuit breaker (MCB), Acti9 C120N, 1P, 63A, C curve, 10000A (IEC/EN 60898-1), 10kA (IEC/EN 60947-2).
Miniature circuit breaker (MCB), Acti9 C120N, 1P, 63A, C curve, 10000A (IEC/EN 60898-1), 10kA (IEC/EN 60947-2). Genuine Schneider Electric product supplied by United Force.
| Range | Acti9 |
|---|---|
| Product name | Acti9 C120 |
| Product or component type | Miniature circuit-breaker |
| Device short name | C120N |
| Device application | Distribution |
| Poles description | 1P |
| Number of protected poles | 1 |
| [In] rated current | 63 A at 30 °C |
| Network type | AC |
| Trip unit technology | Thermal-magnetic |
| Curve code | C |
| Breaking capacity | 3 kA Icu at 380...415 V AC 50/60 Hz IT conforming to EN/IEC 60947-2 · 20 kA Icu at 130 V AC 50/60 Hz conforming to EN/IEC 60947-2 · 15 kA Icu at 12 V DC conforming to EN/IEC 60947-2 · 15 kA Icu at 125 V DC conforming to EN/IEC 60947-2 · 10 kA Icu at <= 144 V DC conforming to EN/IEC 60947-2 · 10 kA Icu at 220...240 V AC 50/60 Hz conforming to EN/IEC 60947-2 · 20 kA Icu at 12 V AC 50/60 Hz conforming to EN/IEC 60947-2 · 10000 A Icn at 230/400 V AC 50/60 Hz conforming to EN/IEC 60898-1 |
| Suitability for isolation | Yes conforming to IEC 60947-2 |
| Standards | EN/IEC 60947-2 · EN/IEC 60898-1 |
| Product certifications | EAC |
| Network frequency | 50/60 Hz |
| [Ue] rated operational voltage | 380...415 V AC 50/60 Hz · 125 V DC · <= 144 V DC · 12 V DC · 220...240 V AC 50/60 Hz · 230...400 V AC 50/60 Hz · 130 V AC 50/60 Hz · 12 V AC 50/60 Hz |
| Magnetic tripping limit | 5...10 x In |
| [Ics] rated service breaking capacity | 15 kA 75 % conforming to EN/IEC 60947-2 - 130 V AC 50/60 Hz · 15 kA 100 % conforming to EN/IEC 60947-2 - 125 V DC · 2.25 kA 75 % conforming to EN/IEC 60947-2 - 380...415 V AC 50/60 Hz · 15 kA 100 % conforming to EN/IEC 60947-2 - 12 V DC · 10 kA 100 % conforming to EN/IEC 60947-2 - <= 144 V DC · 7.5 kA 75 % conforming to EN/IEC 60947-2 - 220...240 V AC 50/60 Hz · 15 kA 75 % conforming to EN/IEC 60947-2 - 12 V AC 50/60 Hz · 7500 A 75 % conforming to EN/IEC 60898-1 - 230/400 V AC 50/60 Hz |
| Limitation class | 1 conforming to EN/IEC 60947-2 |
| [Ui] rated insulation voltage | 500 V AC 50/60 Hz conforming to EN/IEC 60947-2 |
| [Uimp] rated impulse withstand voltage | 6 kV conforming to EN/IEC 60947-2 |
| Contact position indicator | Yes |
| Control type | Toggle |
| Local signalling | ON/OFF indication |
| Mounting mode | Clip-on |
| Mounting support | 35 mm symmetrical DIN rail |
| Comb busbar and distribution block compatibility | YES |
| 9 mm pitches | 3 |
| Height | 81 mm |
| Depth | 73 mm |
| Width | 27 mm |
| Product weight | 0.205 kg |
| Colour | White |
| Mechanical durability | 20000 cycles |
| Electrical durability | 10000 cycles conforming to IEC 60947-2 |
| Locking options description | Handle sealable with cable diameter 0.7mm in OFF or ON position |
| Connections - terminals | Tunnel type terminals1…50 mm² rigid · Tunnel type terminals1.5…35 mm² flexible |
| Wire stripping length | 15 mm |
| Tightening torque | 3.5 N.m |
| Earth-leakage protection | Without |
| IP degree of protection | IP20 conforming to IEC 60529 |
| Pollution degree | 3 conforming to IEC 60947-2 |
| Overvoltage category | IV |
| Tropicalisation | 2 conforming to IEC 60068-1 |
