Schneider Electric ComPacT NSX basic frame, rated 250 A. Circuit breaker basic frame, ComPacT NSX250H, 70kA/415VAC, 3 poles, 250A frame rating, without trip unit.
Circuit breaker basic frame, ComPacT NSX250H, 70kA/415VAC, 3 poles, 250A frame rating, without trip unit. Genuine Schneider Electric product supplied by United Force.
| Range | ComPacT |
|---|---|
| Product name | ComPacT NSX |
| Device short name | NSX250H |
| Product or component type | Basic frame |
| Device application | Distribution |
| Poles description | 3P |
| [In] rated current | 250 A at 40 °C |
| [Ue] rated operational voltage | 690 V AC 50/60 Hz conforming to IEC 60947-2 |
| Network type | AC |
| Network frequency | 50/60 Hz |
| Suitability for isolation | Yes conforming to EN/IEC 60947-2 |
| Utilisation category | Category A |
| Breaking capacity | 85 kA at 240 V AC 50/60 Hz conforming to UL 508 · 65 kA at 480 V AC 50/60 Hz conforming to UL 508 · 10 kA Icu at 660/690 V AC 50/60 Hz conforming to IEC 60947-2 · 100 kA Icu at 220/240 V AC 50/60 Hz conforming to IEC 60947-2 · 35 kA Icu at 525 V AC 50/60 Hz conforming to IEC 60947-2 · 50 kA Icu at 500 V AC 50/60 Hz conforming to IEC 60947-2 · 65 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2 · 70 kA Icu at 380/415 V AC 50/60 Hz conforming to IEC 60947-2 · 15 kA at 600 V AC 50/60 Hz conforming to UL 508 |
| Breaking capacity code | H 70 kA 415 V AC |
| Control type | Toggle |
| Mounting mode | Fixed |
| [Ui] rated insulation voltage | 800 V AC 50/60 Hz conforming to IEC 60947-2 |
| [Uimp] rated impulse withstand voltage | 8 kV conforming to IEC 60947-2 |
| [Ics] rated service breaking capacity | 10 kA at 660/690 V AC 50/60 Hz conforming to IEC 60947-2 · 100 kA at 220/240 V AC 50/60 Hz conforming to IEC 60947-2 · 35 kA at 525 V AC 50/60 Hz conforming to IEC 60947-2 · 50 kA at 500 V AC 50/60 Hz conforming to IEC 60947-2 · 65 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2 · 70 kA at 380/415 V AC 50/60 Hz conforming to IEC 60947-2 |
| Mechanical durability | 20000 cycles conforming to IEC 60947-2 |
| Electrical durability | 10000 cycles 440 V AC 50/60 Hz In conforming to IEC 60947-2 · 10000 cycles 690 V AC 50/60 Hz In/2 conforming to IEC 60947-2 · 20000 cycles 440 V AC 50/60 Hz In/2 conforming to IEC 60947-2 · 5000 cycles 690 V AC 50/60 Hz In conforming to IEC 60947-2 |
| Mounting support | Backplate |
| Upside connection | Front |
| Downside connection | Front |
| Connection pitch | 35 mm |
| Protection type | Without protection |
| Width (W) | 105 mm |
| Height (H) | 161 mm |
| Depth (D) | 86 mm |
| Standards | EN/IEC 60947-2 · UL 60947-4-1 |
| Overvoltage category | III |
| Electrical shock protection class | Class II on front face |
| Pollution degree | 3 conforming to IEC 60664-1 |
| IP degree of protection | IP40 conforming to IEC 60529 |
| IK degree of protection | IK07 conforming to IEC 62262 |
| Ambient air temperature for operation | -25…70 °C |
| Ambient air temperature for storage | -50…85 °C |
| Unit Type of Package 2 | S03 |
| Number of Units in Package 2 | 7 |
| Package 2 Height | 30.000 cm |
| Package 2 Width | 30.000 cm |
| Package 2 Length | 40.000 cm |
| Package 2 Weight | 11.480 kg |
| Unit Type of Package 3 | P12 |
| Number of Units in Package 3 | 56 |
