Schneider Electric circuit breaker, rated 100 A. circuit breaker,EasyPact EZC250N ,TMD, 100A ,3 poles 3d.
circuit breaker,EasyPact EZC250N ,TMD, 100A ,3 poles 3d. Genuine Schneider Electric product supplied by United Force.
| Range of product | EasyPact |
|---|---|
| Product or component type | Circuit breaker |
| Device short name | Easypact EZC250N |
| Circuit breaker name | Easypact EZC250N |
| Device application | Distribution |
| Poles description | 3P |
| Protected poles description | 3t |
| Network type | DC · AC |
| Network frequency | 50/60 Hz |
| [In] rated current | 100 A at 40 °C |
| [Ui] rated insulation voltage | 690 V AC 50/60 Hz conforming to IEC 60947-2 |
| [Uimp] rated impulse withstand voltage | 6 kV conforming to IEC 60947-2 |
| [Ue] rated operational voltage | 550 V AC 50/60 Hz conforming to IEC 60947-2 · 250 V DC conforming to IEC 60947-2 |
| Breaking capacity code | N |
| Breaking capacity | 20 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2 · 50 kA Icu at 110...130 V AC 50/60 Hz conforming to IEC 60947-2 · 50 kA Icu at 220...240 V AC 50/60 Hz conforming to IEC 60947-2 · 20 kA Icu at 125 V DC 1P conforming to IEC 60947-2 · 20 kA Icu at 250 V DC 2P conforming to IEC 60947-2 · 25 kA Icu at 380 V AC 50/60 Hz conforming to IEC 60947-2 · 25 kA Icu at 400...415 V AC 50/60 Hz conforming to IEC 60947-2 · 8 kA Icu at 550 V AC 50/60 Hz conforming to IEC 60947-2 |
| [Ics] rated service breaking capacity | 10 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2 · 25 kA at 110/130 V AC 50/60 Hz conforming to IEC 60947-2 · 10 kA at 125 V DC conforming to IEC 60947-2 · 10 kA at 250 V DC conforming to IEC 60947-2 · 25 kA at 220/230/240 V AC 50/60 Hz conforming to IEC 60947-2 · 4 kA at 550 V AC 50/60 Hz conforming to IEC 60947-2 · 12.5 kA at 380 V AC 50/60 Hz conforming to IEC 60947-2 · 12.5 kA at 400/415 V AC 50/60 Hz conforming to IEC 60947-2 |
| Suitability for isolation | Yes conforming to IEC 60947-2 |
| Utilisation category | Category A |
| Trip unit name | TM-D |
| Trip unit technology | Thermal-magnetic |
| Trip unit rating | 100 A at 50 °C |
| Protection type | Overload protection · Short-circuit protection |
| Pollution degree | 3 conforming to IEC 60664-1 · 3 conforming to IEC 947-1 |
| Control type | Toggle |
| Mounting mode | Fixed |
| Mounting support | Backplate |
| Upside connection | Front |
| Downside connection | Front |
| Mechanical durability | 10000 cycles |
| Connection pitch | 35 mm |
| Local signalling | Positive contact indication |
| Neutral protection setting | Without protection |
| Earth-leakage protection | Without |
| Height | 165 mm |
| Width | 105 mm |
| Depth | 60 mm |
| Standards | EN/IEC 60947-2 · GB/T 14048.2 · EN/IEC 60947-1 |
| IP degree of protection | IP20 conforming to IEC 60529 |
| IK degree of protection | IK07 conforming to IEC 62262 |
| Ambient air temperature for operation | -25…70 °C |
| Ambient air temperature for storage | -35…85 °C |
| Unit Type of Package 2 | S03 |
| Number of Units in Package 2 | 8 |
| Package 2 Height | 30.000 cm |
| Package 2 Width | 30.000 cm |
