Schneider Electric circuit breaker, rated 630 A. circuit breaker,Easypact EZC630N ,TMD, 500A ,3 poles 3d.
circuit breaker,Easypact EZC630N ,TMD, 500A ,3 poles 3d. Genuine Schneider Electric product supplied by United Force.
| Range of product | EasyPact |
|---|---|
| Product or component type | Circuit breaker |
| Device short name | Easypact EZC630N |
| Circuit breaker name | Easypact EZC630N |
| Device application | Distribution |
| Poles description | 3P |
| Protected poles description | 3t |
| Network type | AC |
| Network frequency | 50/60 Hz |
| [In] rated current | 630 A at 40 °C |
| [Ui] rated insulation voltage | 690 V AC 50/60 Hz conforming to IEC 60947-2 |
| [Uimp] rated impulse withstand voltage | 6 kV conforming to IEC 60947-2 |
| [Ue] rated operational voltage | 440 V AC 50/60 Hz conforming to IEC 60947-2 |
| Breaking capacity code | N |
| Breaking capacity | 36 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2 · 40 kA Icu at 220/230 V AC 50/60 Hz conforming to IEC 60947-2 · 36 kA Icu at 380 V AC 50/60 Hz conforming to IEC 60947-2 · 36 kA Icu at 400/415 V AC 50/60 Hz conforming to IEC 60947-2 |
| [Ics] rated service breaking capacity | 18 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2 · 40 kA at 220/230 V AC 50/60 Hz conforming to IEC 60947-2 · 36 kA at 380 V AC 50/60 Hz conforming to IEC 60947-2 · 36 kA at 400/415 V AC 50/60 Hz conforming to IEC 60947-2 |
| Suitability for isolation | Yes conforming to IEC 60947-2 |
| Utilisation category | Category A |
| Trip unit name | TM-D |
| Trip unit technology | Thermal-magnetic |
| Trip unit rating | 500 A at 50 °C |
| Protection type | Short-circuit protection · Overload protection |
| Pollution degree | 3 conforming to IEC 60947 |
| Control type | Toggle |
| Mounting mode | Fixed |
| Mounting support | Backplate |
| Upside connection | Front |
| Downside connection | Front |
| Mechanical durability | 10000 cycles |
| Electrical durability | Category A: 3000 cycles 415 V AC 50/60 Hz conforming to IEC 60947-2 |
| Connection pitch | 45 mm |
| Local signalling | Positive contact indication |
| Contact position indicator | Yes |
| Magnetic tripping current | 5000 A |
| Neutral protection setting | Without protection |
| Long time pick-up adjustment type Ir | Fixed |
| Long time delay adjustment type | Fixed |
| Earth-leakage protection | Without |
| Height | 255 mm |
| Width | 140 mm |
| Depth | 110 mm |
| Product weight | 6.4 kg |
| Quantity per set | 1 piece |
| Colour | Black |
| Standards | EN/IEC 60947-2 · GB/T 14048.2 · JIS C8201-2-2 · EN/IEC 60947-1 |
