Schneider Electric ComPacT basic frame, rated 1600 A. Circuit breaker frame, ComPacT NS1600N, 50kA at 415VAC, 1600A, 3P, fixed, manually operated, without control unit.
Circuit breaker frame, ComPacT NS1600N, 50kA at 415VAC, 1600A, 3P, fixed, manually operated, without control unit. Genuine Schneider Electric product supplied by United Force.
Technical specifications
| Range | ComPacT |
|---|
| Range of product | ComPacT NS630b...1600 new generation |
|---|
| Product or component type | Basic frame |
|---|
| Device application | Distribution |
|---|
| Number of poles | 3P |
|---|
| [In] rated current | 1600 A at 50 °C |
|---|
| [Ue] rated operational voltage | 690 V AC 50/60 Hz |
|---|
| Network type | AC |
|---|
| Network frequency | 50/60 Hz |
|---|
| Suitability for isolation | Yes conforming to EN/IEC 60947-2 |
|---|
| Utilisation category | Category B |
|---|
| Breaking capacity | 85 kA Icu at 220/240 V AC 50/60 Hz conforming to IEC 60947-2 · 50 kA Icu at 380/415 V AC 50/60 Hz conforming to IEC 60947-2 · 50 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2 · 40 kA Icu at 500/525 V AC 50/60 Hz conforming to IEC 60947-2 · 30 kA Icu at 660/690 V AC 50/60 Hz conforming to IEC 60947-2 |
|---|
| Breaking capacity code | N 50 kA 415 V AC |
|---|
| Control type | Manually operated |
|---|
| Mounting mode | Fixed |
|---|
| [Ui] rated insulation voltage | 800 V AC 50/60 Hz conforming to IEC 60947-2 |
|---|
| [Uimp] rated impulse withstand voltage | 8 kV conforming to IEC 60947-2 |
|---|
| [Ics] rated service breaking capacity | 37 kA at 220/240 V AC 50/60 Hz conforming to IEC 60947-2 · 37 kA at 380/415 V AC 50/60 Hz conforming to IEC 60947-2 · 37 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2 · 30 kA at 500/525 V AC 50/60 Hz conforming to IEC 60947-2 · 22 kA at 660/690 V AC 50/60 Hz conforming to IEC 60947-2 |
|---|
| [Icw] rated short-time withstand current | 19.2 kA 1 s conforming to IEC 60947-2 |
|---|
| Integral instant protection | 40 kA |
|---|
| Mechanical durability | 10000 cycles conforming to IEC 60947-2 |
|---|
| Electrical durability | 1000 cycles 690 V AC 50/60 Hz In conforming to IEC 60947-2 · 2000 cycles 690 V AC 50/60 Hz In/2 conforming to IEC 60947-2 · 2000 cycles 440 V AC 50/60 Hz In conforming to IEC 60947-2 · 5000 cycles 440 V AC 50/60 Hz In/2 conforming to IEC 60947-2 |
|---|
| Power losses | 74 W |
|---|
| Mounting support | Backplate |
|---|
| Connection pitch | 70 mm |
|---|
| Protection type | Without protection |
|---|
| Height (H) | 224 mm |
|---|
| Width (W) | 210 mm |
|---|
| Depth (D) | 147 mm |
|---|
| Standards | IEC 60947-2 |
|---|
| Product certifications | IECEE CB Scheme |
|---|
| Overvoltage category | III |
|---|
| Electrical shock protection class | Class II on front face |
|---|
| Pollution degree | 3 conforming to IEC 60947 |
|---|
| IP degree of protection | IP40 conforming to IEC 60529 |
|---|
| IK degree of protection | IK07 conforming to EN 50102 |
|---|
| Ambient air temperature for operation | -25…70 °C |
|---|
| Ambient air temperature for storage | -50…85 °C |
|---|
| Warranty (in months) | 18 |
|---|
