Schneider Electric ComPacT basic frame, rated 630 A. Circuit breaker frame, ComPacT NS630bL, 150kA at 415VAC, 630A, 3P, withdrawable, manually operated, without control unit.
Circuit breaker frame, ComPacT NS630bL, 150kA at 415VAC, 630A, 3P, withdrawable, manually operated, without control unit. Genuine Schneider Electric product supplied by United Force.
Technical specifications
| Range | ComPacT |
|---|
| Range of product | ComPacT NS630b...1600 new generation |
|---|
| Product or component type | Basic frame |
|---|
| Device application | Distribution |
|---|
| Number of poles | 3P |
|---|
| [In] rated current | 630 A at 50 °C |
|---|
| [Ue] rated operational voltage | 690 V AC 50/60 Hz |
|---|
| Network type | AC |
|---|
| Network frequency | 50/60 Hz |
|---|
| Suitability for isolation | Yes conforming to EN/IEC 60947-2 |
|---|
| Utilisation category | Category A |
|---|
| Breaking capacity | 150 kA Icu at 220/240 V AC 50/60 Hz conforming to IEC 60947-2 · 150 kA Icu at 380/415 V AC 50/60 Hz conforming to IEC 60947-2 · 130 kA Icu at 440 V AC 50/60 Hz conforming to IEC 60947-2 · 100 kA Icu at 500/525 V AC 50/60 Hz conforming to IEC 60947-2 |
|---|
| Breaking capacity code | L 150 kA 415 V AC |
|---|
| Control type | Manually operated |
|---|
| Mounting mode | Withdrawable |
|---|
| [Ui] rated insulation voltage | 800 V AC 50/60 Hz conforming to IEC 60947-2 |
|---|
| [Uimp] rated impulse withstand voltage | 8 kV conforming to IEC 60947-2 |
|---|
| [Ics] rated service breaking capacity | 150 kA at 220/240 V AC 50/60 Hz conforming to IEC 60947-2 · 150 kA at 380/415 V AC 50/60 Hz conforming to IEC 60947-2 · 130 kA at 440 V AC 50/60 Hz conforming to IEC 60947-2 · 100 kA at 500/525 V AC 50/60 Hz conforming to IEC 60947-2 |
|---|
| [Icw] rated short-time withstand current | 19.2 kA 1 s conforming to IEC 60947-2 |
|---|
| Integral instant protection | 40 kA |
|---|
| Mechanical durability | 10000 cycles conforming to IEC 60947-2 |
|---|
| Electrical durability | 2000 cycles 690 V AC 50/60 Hz In conforming to IEC 60947-2 · 3000 cycles 690 V AC 50/60 Hz In/2 conforming to IEC 60947-2 · 3000 cycles 440 V AC 50/60 Hz In conforming to IEC 60947-2 · 4000 cycles 440 V AC 50/60 Hz In/2 conforming to IEC 60947-2 |
|---|
| Power losses | 34 W |
|---|
| Mounting support | Backplate |
|---|
| Connection pitch | 70 mm |
|---|
| Protection type | Without protection |
|---|
| Height (H) | 260 mm |
|---|
| Width (W) | 236 mm |
|---|
| Depth (D) | 147 mm |
|---|
| Standards | IEC 60947-2 |
|---|
| Product certifications | IECEE CB Scheme |
|---|
| Overvoltage category | III |
|---|
| Electrical shock protection class | Class II on front face |
|---|
| Pollution degree | 3 conforming to IEC 60947 |
|---|
| IP degree of protection | IP40 conforming to IEC 60529 |
|---|
| IK degree of protection | IK07 conforming to EN 50102 |
|---|
| Ambient air temperature for operation | -25…70 °C |
|---|
| Ambient air temperature for storage | -50…85 °C |
|---|
| Warranty (in months) | 18 |
|---|
