Schneider Electric VigiPacT earth leakage current sensor, rated 85 A. Closed toroid A type, VigiPacT, Vigilohm, PA50, inner diameter 50mm, rated current 85A.
Closed toroid A type, VigiPacT, Vigilohm, PA50, inner diameter 50mm, rated current 85A. Genuine Schneider Electric product supplied by United Force.
| Range | VigiPacT |
|---|---|
| Device short name | PA50 |
| Product or component type | Earth leakage current sensor |
| Device application | Equipment monitoring and control |
| Range compatibility | VigiPacT RH10M residual current protection relay · VigiPacT RH10P residual current protection relay · VigiPacT RH21M residual current protection relay · VigiPacT RH21P residual current protection relay · VigiPacT RH68M residual current protection relay · VigiPacT RH86M residual current protection relay · VigiPacT RH86P residual current protection relay · VigiPacT RH99M residual current protection relay · VigiPacT RH99P residual current protection relay · VigiPacT RH197M residual current protection relay · VigiPacT RH197P residual current protection relay · VigiPacT RHU residual current protection relay · VigiPacT RHUs residual current protection relay · VigiPacT RMH residual current protection relay |
| current sensor type | A type closed toroid |
| [Ie] rated operational current | 85 A |
| Transformer ratio | 1/1000 |
| Network frequency | 50/60 Hz · 400 Hz |
| [Icw] rated short-time withstand current | 85 kA for 0.5 s |
| Residual short-circuit withstand current | 85 kA / 0.5 s conforming to IEC 60947-2 |
| [Ui] rated insulation voltage | 1000 V |
| Overvoltage category | IV |
| [Uimp] rated impulse withstand voltage | 12 kV |
| Mounting mode | Fixed (plain backplate) · Fixed (profiled sheet metal) · Fixed (slotted backplate) · Clip-on (DIN rail) · Clip-on (Vigirex relay) |
| Calorific value | 1.42 MJ |
| Connections - terminals | Screw connection 0.22…2.5 mm² |
| Diameter | 50.4 mm inner: |
| Product weight | 0.2 kg |
| Height | 100 mm |
| Width | 88 mm |
| Depth | 29 mm |
| IP degree of protection | IP30 · Connectors: IP20 |
| Environmental characteristic | Exposure to damp heat in service: category C2: 48 hours conforming to IEC 60068-2-56 · Exposure to damp heat not in service (25...55 °C, RH 95 %) : 28 cycles conforming to IEC 60068-2-30 · Salt mist: Kb/2 conforming to IEC 60068-2-52 |
| Pollution degree | Level 3 conforming to IEC 60664-1 |
| Ambient air temperature for operation | -35…70 °C |
| Ambient air temperature for storage | -55…85 °C |
| Standards | IEC 60947-2 |
| Product certifications | CE |
| Unit Type of Package 2 | S04 |
| Number of Units in Package 2 | 100 |
| Package 2 Height | 30.000 cm |
| Package 2 Width | 40.000 cm |
| Package 2 Length | 60.000 cm |
| Package 2 Weight | 18.766 kg |
| Warranty (in months) | 18 |
