Schneider Electric Easy TeSys contactor, rated 40 A. Contactor,Easy TeSys Control,LC1E,4P(4NO),AC-1 40A,220V.
Contactor,Easy TeSys Control,LC1E,4P(4NO),AC-1 40A,220V. Genuine Schneider Electric product supplied by United Force.
| Range | Easy TeSys |
|---|---|
| Range of product | Easy TeSys Control |
| Product or component type | Contactor |
| Device short name | LC1E |
| Contactor application | Resistive load |
| Utilisation category | AC-1 |
| Poles description | 4P |
| [Ue] rated operational voltage | Power circuit: <= 690 V AC 50/60 Hz |
| [Ie] rated operational current | 40 A (at <55 °C) at <= 440 V AC AC-1 for power circuit |
| [Uc] control circuit voltage | 220 V AC 50/60 Hz |
| Pole contact composition | 4 NO |
| [Ith] conventional free air thermal current | 40 A (at 55 °C) for power circuit |
| Irms rated making capacity | 250 A at 440 V AC for power circuit conforming to IEC 60947-4-1 |
| Rated breaking capacity | 200 A at 440 V for power circuit conforming to IEC 60947 |
| [Icw] rated short-time withstand current | 240 A 40 °C - 10 s for power circuit · 120 A 40 °C - 60 s for power circuit · 50 A 40 °C - 600 s for power circuit |
| Associated fuse rating | 40 A gG at <= 690 V coordination type 1 for power circuit |
| Average impedance | 2.5 mOhm - Ith 40 A 50 Hz for power circuit |
| Power dissipation per pole | 1.6 W AC-3 · 3.2 W AC-1 |
| [Ui] rated insulation voltage | 690 V conforming to IEC 60947-4-1 |
| Overvoltage category | III |
| Pollution degree | 3 |
| [Uimp] rated impulse withstand voltage | 6 kV conforming to IEC 60947 |
| Mechanical durability | 10000000 cycles |
| Electrical durability | 1200000 cycles AC-3 · 350000 cycles AC-1 |
| Control circuit type | AC at 50/60 Hz |
| Control circuit voltage limits | 0.85...1.1 Uc (-5…55 °C):operational 50/60 Hz · 0.3...0.6 Uc (-5…55 °C):drop-out 50/60 Hz |
| Inrush power in VA | 95 VA 50 Hz cos phi 0.75 (at 20 °C) · 95 VA 60 Hz cos phi 0.75 (at 20 °C) |
| Hold-in power consumption in VA | 8.3 VA 50 Hz cos phi 0.3 (at 20 °C) · 8.5 VA 60 Hz cos phi 0.3 (at 20 °C) |
| Heat dissipation | 2…3 W for control circuit |
| Operating time | 12...22 ms on closing · 4...19 ms on opening |
| Maximum operating rate | 1800 cyc/h 60 °C |
| Connections - terminals | Control circuit: screw clamp terminals 1 1…4 mm² - cable stiffness: flexible without cable end · Control circuit: screw clamp terminals 2 1…4 mm² - cable stiffness: flexible without cable end · Control circuit: screw clamp terminals 1 1…4 mm² - cable stiffness: flexible with cable end · Control circuit: screw clamp terminals 2 1…2.5 mm² - cable stiffness: flexible with cable end · Control circuit: screw clamp terminals 1 1…4 mm² - cable stiffness: solid without cable end · Control circuit: screw clamp terminals 2 1…4 mm² - cable stiffness: solid without cable end · Power circuit: screw clamp terminals 1 1.5…6 mm² - cable stiffness: solid without cable end · Power circuit: screw clamp terminals 2 1.5…6 mm² - cable stiffness: solid without cable end · Power circuit: screw clamp terminals 1 1…6 mm² - cable stiffness: flexible with cable end · Power circuit: screw clamp terminals 2 1…4 mm² - cable stiffness: flexible with cable end |
| Tightening torque | Control circuit: 1.2 N.m · Power circuit: 1.5 N.m |
| Auxiliary contact composition | Without |
| Mounting support | DIN rail · Plate |
| Standards | EN/IEC 60947-1 · EN/IEC 60947-4-1 · GB/T 14048.1 · GB/T 14048.4 |
| Product certifications | CB Scheme · CCC · CE · EAC |
| IP degree of protection | IP2X conforming to IEC 60529 |
| Protective treatment | TH (pollution degree 3) conforming to IEC 60068-2-30 test Db |
| Permissible ambient air temperature around the device | -20…70 °C at Uc · -60…80 °C storage · -5…55 °C operation |
| Operating altitude | 3000 m without derating |
| Fire resistance | 850 °C conforming to IEC 60695-2-1 |
| Mechanical robustness | Vibrations contactor open (1.5 Gn, 5...300 Hz) · Vibrations contactor closed (3 Gn, 5...300 Hz) · Shocks contactor closed (10 Gn for 11 ms) · Shocks contactor open (6 Gn for 11 ms) |
| Height | 64 mm |
| Width | 56 mm |
