Schneider Electric Disbo iC60 miniature circuit-breaker, rated 10 A. Miniature circuit breaker (MCB), Acti9 iC60N Disbo, 1P, 10A, C curve, 6000A (IEC/EN 60898-1), 10kA (IEC/EN 60947-2).
Miniature circuit breaker (MCB), Acti9 iC60N Disbo, 1P, 10A, C curve, 6000A (IEC/EN 60898-1), 10kA (IEC/EN 60947-2). Genuine Schneider Electric product supplied by United Force.
| Range | Acti9 |
|---|---|
| Product name | Disbo iC60 |
| Product or component type | Miniature circuit-breaker |
| Device short name | IC60N |
| Poles description | 1P |
| Number of protected poles | 1 |
| [In] rated current | 10 A |
| Network type | AC/DC |
| Trip unit technology | Thermal-magnetic |
| Curve code | C |
| Breaking capacity | 36 kA Icu at 10...60 V AC 50/60 Hz conforming to EN/IEC 60947-2 · 20 kA Icu at 100...133 V AC 50/60 Hz conforming to EN/IEC 60947-2 · 10 kA Icu at 220...240 V AC 50/60 Hz conforming to EN/IEC 60947-2 · 15 kA Icu at 12...60 V DC conforming to EN/IEC 60947-2 · 10 kA Icu at 60...72 V DC conforming to EN/IEC 60947-2 · 6000 A Icn at 240 V AC 50/60 Hz conforming to EN/IEC 60898-1 |
| Utilisation category | Category A conforming to EN/IEC 60947-2 |
| Network frequency | 50/60 Hz |
| [Ue] rated operational voltage | 12...60 V AC 50/60 Hz · 100...133 V AC 50/60 Hz · 220...240 V AC 50/60 Hz · 12...60 V DC · 60...72 V DC |
| Magnetic tripping limit | 8 x In +/- 20 % |
| [Ics] rated service breaking capacity | 27 kA 75 % conforming to EN/IEC 60947-2 - 12...60 V AC 50/60 Hz · 15 kA 75 % conforming to EN/IEC 60947-2 - 100...133 V AC 50/60 Hz · 7.5 kA 75 % conforming to EN/IEC 60947-2 - 220...240 V AC 50/60 Hz · 15 kA 100 % conforming to EN/IEC 60947-2 - 12...60 V DC · 10 kA 100 % conforming to EN/IEC 60947-2 - 60...72 V DC |
| Limitation class | 3 conforming to EN/IEC 60898-1 |
| [Ui] rated insulation voltage | 500 V AC 50/60 Hz conforming to EN/IEC 60947-2 |
| [Uimp] rated impulse withstand voltage | 6 kV conforming to EN/IEC 60947-2 |
| Contact position indicator | Yes |
| Control type | Toggle |
| Local signalling | Trip indicator |
| Mounting mode | Clip-on |
| Mounting support | Rail |
| 9 mm pitches | 2 |
| Height | 85 mm |
| Width | 18 mm |
| Depth | 78.5 mm |
| Product weight | 0.125 kg |
| Colour | White |
| Mechanical durability | 20000 cycles |
| Electrical durability | 10000 cycles |
| Provision for padlocking | Padlockable |
| Connections - terminals | Single terminal (top or bottom) 1…25 mm² rigid · Single terminal (top or bottom) 1…16 mm² flexible |
| Wire stripping length | 14 mm for top or bottom connection |
| Tightening torque | 2 N.m top or bottom |
| Earth-leakage protection | Separate block |
| Standards | EN/IEC 60898-1 · EN/IEC 60947-2 |
| IP degree of protection | IP20 conforming to IEC 60529 |
| Pollution degree | 3 conforming to EN/IEC 60947-2 |
| Overvoltage category | IV |
| Tropicalisation | 2 conforming to IEC 60068-1 |
| Relative humidity | 95 % at 55 °C |
| Ambient air temperature for operation | -35…70 °C |
| Ambient air temperature for storage | -40…85 °C |
