Schneider Electric MasterPacT control unit. MicroLogic Active 5.0AP control unit, wireless, MasterPacT MTZ1, drawout circuit breakers, LSI protections.
MicroLogic Active 5.0AP control unit, wireless, MasterPacT MTZ1, drawout circuit breakers, LSI protections. Genuine Schneider Electric product supplied by United Force.
| Range | MasterPacT |
|---|---|
| Device short name | MicroLogic Active 5.0 AP |
| Product or component type | Control unit |
| Device application | Equipment protection, monitoring and control |
| Circuit breaker application | Distribution IEC standard |
| Range compatibility | MasterPacT MTZ1 Active circuit breaker |
| Poles | 4P · 3P |
| Protected poles description | 3P 3d · 4P 3d · 4P 3d + N/2 · 4P 4d · 4P 3d + OSN |
| [Ue] rated operational voltage | 690 V AC, +/- 10 % |
| Network type | AC |
| Network frequency | 50/60 Hz |
| Trip unit technology | Electronic |
| Trip unit protection functions | LSI |
| Protection type | Overload protection (long time) conforming to ANSI 49 · Instantaneous short-circuit protection conforming to ANSI 50 · Short time short-circuit protection conforming to ANSI 51 |
| Trip unit rating | 250 A · 400 A · 630 A · 800 A · 1000 A · 1250 A · 1600 A |
| Mounting mode | Drawout |
| Neutral protection setting | 1 x Ir (4P 4d) · 0.5 x Ir (4P 3d + N/2) · 1.6 x Ir (4P 3d + OSN) · No protection (4P 3d) |
| [Ir] long time pick-up adjustment range | 0.4...1 x In adjustable in step of 1 A |
| Long time delay adjustment type | Adjustable in step of 0.5 s |
| [tr] long-time delay adjustment range | 0.5…24 s at 6 x Ir |
| Thermal memory | Yes |
| [Isd] short-time pick-up adjustment range | 1.5...10 x Ir adjustable in step of 0.1 x Ir |
| Short-time delay adjustment type | Adjustable |
| [tsd] short-time delay adjustment range | 0.1…0.8 s I²t=on · 0…0.8 s I²t=off |
| Instantaneous pick-up adjustment type Ii | Adjustable |
| [Ii] instantaneous pick-up adjustment range | 2...15 x In adjustable in step of 0.1 x In · Ii enable on/off |
| [li mode] instantaneous delay adjustment range | 20 ms in standard |
| Zone selective interlocking ZSI | With |
| Network and machine diagnosis type | System (HMI) health state overview: circuit breaker health state · Contacts state: circuit breaker health state · MicroLogic service life: circuit breaker health state · Tripping cause indication: circuit breaker tripping cause · Identification card: diagnostic data · Configured alarms synthesis: diagnostic data · Monitored function: diagnostic data · Operation: diagnostic data · MicroLogic test: test · Protection test: test · Selectivity test: test · Trip context information: crisis management · Operation: advanced diagnostic · Breaker service life: circuit breaker health state |
| Type of measurement | Ammeter |
| Metering type | Current I1, I2, I3, Iavg RMS · Neutral current IN RMS · Ground fault current Ig RMS · Demand current I1, I2, I3, In, Iavg · Frequency · Phase sequence total · Unbalance current |
| Frequency measurement range | 40…70 Hz |
| Measurement accuracy | Current I1, I2, I3, Iavg, Idemand for MTZ1: +/- 1.5 % 40...1600 x 1.2 A · Current I1, I2, I3, Iavg, Idemand for MTZ2: +/- 1.5 % 40...4000 x 1.2 A · Current I1, I2, I3, Iavg, Idemand for MTZ3: +/- 1.5 % 80...6300 x 1.2 A · Neutral current IN: +/- 1.5 % · Ground fault current Ig: +/- 10 % · Frequency: +/- 0.005 Hz · Unbalance current: +/- 0.5 % |
| Display type | LCD display - 320 x 240 pixels |
| Communication port protocol | Bluetooth 5.0 LE peer to peer 30 kbit/s · NFC peer to peer 28800 bauds conforming to ISO 15963 · USB peer to peer 115 kbauds |
| Data recording | Data logs · Event logs · Alarm logs · Time stamping · Maintenance logs · Min/max of instantaneous values |
| Standards | EN/IEC 60947-2 · EN/IEC 60092-202 · EN/IEC 60947-1 · EN/IEC 60255-1 · EN/IEC 61010-1 · IEEE 802.15.4 |
| Mounting location | Indoor use only |
| Environmental characteristic | Wet location not approved for use conforming to IEC 61010-1 |
| Electromagnetic compatibility | Electrostatic discharge immunity test conforming to IEC 61000-4-2 · Susceptibility to electromagnetic fields conforming to IEC 61000-4-3 · Electrical fast transient/burst immunity test conforming to IEC 61000-4-4 · 1.2/50 µs shock waves immunity test conforming to IEC 61000-4-5 · Conducted RF disturbances conforming to IEC 61000-4-6 · Conducted and radiated emissions A conforming to CISPR 22 |
| Overvoltage category | IV conforming to IEC 61010-1 |
| Measurement category | Category IV conforming to IEC 61010-2-30 |
| Pollution degree | 3 conforming to IEC 60947-1 |
| Ambient air temperature for operation | -25…70 °C (operating) · -35 °C (for start-up of product) |
| Relative humidity | 95 % at 55 °C conforming to IEC 60068-2-30 |
