| Range | MasterPacT |
|---|
| Device short name | MicroLogic Active 6.0 EP |
|---|
| Product or component type | Control unit |
|---|
| Device application | Equipment protection, monitoring and control |
|---|
| Circuit breaker application | Distribution IEC standard |
|---|
| Range compatibility | MasterPacT MTZ1 Active circuit breaker · MasterPacT MTZ2 Active circuit breaker · MasterPacT MTZ3 Active circuit breaker |
|---|
| Poles | 4P · 3P |
|---|
| Protected poles description | 3P 3d · 4P 3d · 4P 3d + N/2 · 4P 4d · 4P 3d + OSN |
|---|
| [Ue] rated operational voltage | 690 V AC, +/- 10 % |
|---|
| Network type | AC |
|---|
| Network frequency | 50/60 Hz |
|---|
| Trip unit technology | Electronic |
|---|
| Trip unit protection functions | LSIG |
|---|
| Protection type | Overload protection (long time) conforming to ANSI 49 · Instantaneous short-circuit protection conforming to ANSI 50 · Short time short-circuit protection conforming to ANSI 51 · Earth fault conforming to ANSI 51N |
|---|
| Trip unit rating | 250 A · 400 A · 630 A · 800 A · 1000 A · 1250 A · 1600 A · 2000 A · 2500 A · 3200 A · 4000 A · 5000 A · 6300 A |
|---|
| Mounting mode | Fixed |
|---|
| Neutral protection setting | 1 x Ir (4P 4d) · 0.5 x Ir (4P 3d + N/2) · 1.6 x Ir (4P 3d + OSN) · No protection (4P 3d) |
|---|
| [Ir] long time pick-up adjustment range | 0.4...1 x In adjustable in step of 1 A |
|---|
| Long time delay adjustment type | Adjustable in step of 0.5 s |
|---|
| [tr] long-time delay adjustment range | 0.5…30 s at 6 x Ir |
|---|
| Thermal memory | Yes |
|---|
| [Isd] short-time pick-up adjustment range | 1.5...10 x Ir adjustable in step of 0.1 x Ir |
|---|
| Short-time delay adjustment type | Adjustable |
|---|
| [tsd] short-time delay adjustment range | 0.1…0.8 s I²t=on · 0…0.8 s I²t=off |
|---|
| Instantaneous pick-up adjustment type Ii | Adjustable |
|---|
| [Ii] instantaneous pick-up adjustment range | 2...15 x In adjustable in step of 0.1 x In · Ii enable on/off |
|---|
| [li mode] instantaneous delay adjustment range | 20 ms in standard |
|---|
| Ground-fault pick-up adjustment type | Adjustable |
|---|
| [Ig] ground-fault pick-up adjustment range | with In 1000 A 0.2...1 x In adjustable in step of 10 A · Ig enable on/off |
|---|
| ground-fault time delay adjustment type | Adjustable |
|---|
| [tg] Ground-fault time delay adjustment range | 0.1…1 s I²t=on · 0…1 s I²t=off |
|---|
| Zone selective interlocking ZSI | With |
|---|
| Network and machine diagnosis type | System (HMI) health state overview: circuit breaker health state · Contacts state: circuit breaker health state · MicroLogic service life: circuit breaker health state · Tripping cause indication: circuit breaker tripping cause · Identification card: diagnostic data · Configured alarms synthesis: diagnostic data · Monitored function: diagnostic data · Operation: diagnostic data · MicroLogic test: test · Protection test: test · Selectivity test: test · Trip context information: crisis management · Operation: advanced diagnostic · Breaker service life: circuit breaker health state |
|---|
| Type of measurement | Energy meter · Ammeter |
|---|
| Energy management | Measurement ,active, reactive and apparent energy · Measurement ,electrical network · Measurement ,energy |
|---|
| Metering type | Current I1, I2, I3, Iavg RMS · Neutral current IN RMS · Ground fault current Ig RMS · Voltage V12, V23, V31, VLLavg RMS · Voltage V1N, V2N, V3N, VLNavg RMS · Active power P, P1, P2, P3 total · Active energy Ep IN/OUT/tot · Power factor · Demand current I1, I2, I3, In, Iavg · Frequency · Phase sequence · Unbalance current |
|---|
| Measurement voltage | 208…828 V AC 50/60 Hz phase to phase · 120…480 V AC 50/60 Hz phase to neutral |
|---|
| Frequency measurement range | 40…70 Hz |
|---|
| Measurement accuracy | Current I1, I2, I3, Iavg, Idemand for MTZ1: +/- 1.5 % 40...1600 x 1.2 A · Current I1, I2, I3, Iavg, Idemand for MTZ2: +/- 1.5 % 40...4000 x 1.2 A · Current I1, I2, I3, Iavg, Idemand for MTZ3: +/- 1.5 % 80...6300 x 1.2 A · Neutral current IN: +/- 1.5 % · Ground fault current Ig: +/- 10 % · Voltage V12, V23, V31, VLLavg: +/- 0.5 % 208...690 x 1.2 V · Voltage V1N, V2N, V3N, VLNavg: +/- 0.5 % 120...400 x 1.2 V · Active power P, P1, P2, P3, Pdemand: +/- 2 % · Active energy Ep IN/OUT/tot: +/- 2 % · Power factor: +/- 2 % · Frequency: +/- 0.005 Hz · Unbalance current: +/- 0.5 % |
|---|
| Accuracy class | Class 0.5: unbalance voltage |
|---|
| Display type | LCD display - 320 x 240 pixels |
|---|
| Communication port protocol | Bluetooth 5.0 LE peer to peer 30 kbit/s · NFC peer to peer 28800 bauds conforming to ISO 15963 · USB peer to peer 115 kbauds |
|---|
| Data recording | Data logs · Event logs · Alarm logs · Time stamping · Maintenance logs · Min/max of instantaneous values |
|---|
| Standards | EN/IEC 60947-2 · EN/IEC 60092-202 · EN/IEC 60947-1 · EN/IEC 60255-1 · EN/IEC 61010-1 · IEEE 802.15.4 |
|---|
| Mounting location | Indoor use only |
|---|
