Schneider Electric MasterPact. Digital module, MasterPact MTZ, ANSI 27/59 - under/over voltage, MicroLogic X control unit.
Digital module, MasterPact MTZ, ANSI 27/59 - under/over voltage, MicroLogic X control unit. Genuine Schneider Electric product supplied by United Force.
| Range | MasterPact |
|---|---|
| Application description | Undervoltage ANSI 27 · Overvoltage ANSI 59 |
| Range compatibility | MasterPact MTZ1 circuit breaker · MasterPact MTZ2 circuit breaker · MasterPact MTZ3 circuit breaker |
| Product compatibility | control unit MicroLogic 2.0 X · control unit MicroLogic 3.0 X · control unit MicroLogic 5.0 X · control unit MicroLogic 6.0 X · control unit MicroLogic 7.0 X · control unit MicroLogic 3.0 Xi · control unit MicroLogic 5.0 Xi · control unit MicroLogic 6.0 Xi |
| Function of module | Protection |
| Service description | Circuit breaker trips when the voltage exceeds the settings · Under/overvoltage protection monitors V12, V23, V31 or V1N, V2N, V3N |
| Service benefits | Typical actions: load shedding, source changeover, emergency generator starting · Protection of the generators · Enable action to be initiated to safeguard the operation of the installation |
| Energy management | Network management (option) |
| Protection type | Undervoltage ANSI code: 27 (option) · Overvoltage ANSI code: 59 (option) |
| Software name | EcoStruxure Power Commission |
| Warranty (in months) | 18 |
