Schneider Electric I/O Modules i/o module. Central I/O module, SpaceLogic, 8 Form C relay digital outputs.
Central I/O module, SpaceLogic, 8 Form C relay digital outputs. Genuine Schneider Electric product supplied by United Force.
| Flame retardance | UL94V0-5VB |
|---|---|
| Width | 30 mm |
| Product certifications | ICES-003 · FCC part 15 class B · CE · RCM |
| Power consumption in VA | 2.2 W |
| Product weight | 209 g |
| Product or component type | I/O module |
| Device short name | DO-FC-8 |
| Height | 114 mm |
| Ambient air temperature for storage | -20…70 °C |
| Depth | 64 mm |
| Ambient air temperature for operation | 0…50 °C |
| IP degree of protection | IP20 |
| Relative humidity | 0…95 % non-condensing |
| Product name | I/O Modules |
| Product brand | Schneider Electric |
| Range | EcoStruxure Building Operation |
| Discrete output number | 8 |
| Mounting support | Wall · DIN rail |
| Electrical connection | Plug-in sub-base |
| Control type | Without |
| Discrete input voltage | 24 V |
| Discrete output type | Relay |
| Local signalling | LED (green) for relay energised |
| Range compatibility | EcoStruxure Building Operation TB-IO-W1 terminal base |
| Standards | UL 864 · UL 916 · FCC CFR 47 part 15 |
| Material | ABS + PC |
| Unit Type of Package 2 | S02 |
| Number of Units in Package 2 | 18 |
| Package 2 Height | 15.000 cm |
| Package 2 Width | 30.000 cm |
| Package 2 Length | 40.000 cm |
| Package 2 Weight | 4.505 kg |
| Warranty (in months) | 18 |
