Schneider Electric EcoStruxure Security Expert door expansion module. Security Expert security purpose door expansion module.
Security Expert security purpose door expansion module. Genuine Schneider Electric product supplied by United Force.
| Width | 90 mm |
|---|---|
| Product certifications | CE · ACMA |
| Device application | Equipment monitoring and control |
| Product weight | 426 g |
| Product or component type | Door expansion module |
| Device short name | SP-RDM2 |
| Function available | Firmware update |
| Height | 60 mm |
| Colour | Black |
| Directives | 2014/30/EU - electromagnetic compatibility · 2014/35/EU - low voltage directive |
| [In] rated current | 80 mA |
| Ambient air temperature for storage | -10…85 °C |
| Ambient air temperature for operation | 0…50 °C |
| Discrete input type | 16 trouble input · 8 high security monitored input · 2 reader input for standard input (Wiegand) · 4 reader input for duplex mode input (Wiegand) · 4 reader input (RS485) |
| Input/output type | 2 form C relay output · 6 open collector NPN output |
| Number of port | 2 RS485/Wiegand |
| Output voltage | 10.83...14 V DC,0.7 A |
| Output current | <= 7 A · <= 50 mA |
| Relative humidity | 0…93 % non-condensing |
| Product brand | Schneider Electric |
| Range | EcoStruxure Security Expert |
| Offline operation | All users access · Access for first 10 user plus 150 card cache · No users access |
| Mounting support | DIN rail |
| Output current limits | 1.1 A |
| Maximum supply current | 1.56 A |
| Environmental characteristic | Indoor use |
| Quality labels | RCM |
| Standards | EN 50131-1:2006 · EN 50131-3:2009 · EN 50131-6:2008 · FCC CFR 47 part 15: class A · ICES-003 class A · UL 294 · CAN/ULC-S319-05 |
| Local signalling | 1 LED (green) for power · 1 LED (green/red) for status · 1 LED (red) for fault · 8 LED (green/red) for input status · 2 LED (red) for relay ON · 2 LED (red) for reader data |
| Range compatibility | EcoStruxure Security Expert controller |
| Operating time | 10 ms...1 h for programmable contact input |
| Warranty (in months) | 18 |
