Schneider Electric TeSys LG enclosed dol starter. Enclosed DOL starter,TeSys LG,9-14A,380V AC coil,including 1 LC1D,GV2ME,emergency stop,2 pushbuttons,GVAX.
Enclosed DOL starter,TeSys LG,9-14A,380V AC coil,including 1 LC1D,GV2ME,emergency stop,2 pushbuttons,GVAX. Genuine Schneider Electric product supplied by United Force.
Technical specifications
| Range | TeSys |
|---|
| Product name | TeSys LG |
|---|
| Device short name | LG7D |
|---|
| Product or component type | Enclosed DOL starter |
|---|
| Device application | Safety |
|---|
| Utilisation category | AC-3 |
|---|
| Device composition | Contactor · Circuit-breaker |
|---|
| Motor power kW | 3 kW at 220/230 V AC 50/60 Hz · 5.5 kW at 400/415 V AC 50/60 Hz · 5.5 kW at 440 V AC 50/60 Hz |
|---|
| Thermal protection adjustment range | 9…14 A |
|---|
| [Uc] control circuit voltage | 380 V AC 50/60 Hz |
|---|
| Control type | Push-button start white I · Push-button stop black O · Mushroom head push-button emergency stop red |
|---|
| Standards | IEC 60204-1 · IEC 60947-4-1 |
|---|
| Product certifications | CE · UKCA |
|---|
| Cable entry number | 4 2 Pg 13 + 2 Pg 16 top · 4 2 Pg 13 + 2 Pg 16 bottom |
|---|
| Height | 165 mm |
|---|
| Depth | 146 mm |
|---|
| Product weight | 1.6 kg |
|---|
| Width | 175 mm |
|---|
| Material | Polycarbonate |
|---|
| IK degree of protection | IK07 conforming to IEC 60529 |
|---|
| IP degree of protection | IP55 conforming to IEC 60529 |
|---|
| Environmental characteristic | Standard environment |
|---|
| Unit Type of Package 2 | S06 |
|---|
| Number of Units in Package 2 | 12 |
|---|
| Package 2 Height | 75.000 cm |
|---|
| Package 2 Width | 60.000 cm |
|---|
| Package 2 Length | 80.000 cm |
|---|
| Package 2 Weight | 36.016 kg |
|---|
| Warranty (in months) | 18 |
|---|
