Schneider Electric interface module. IFE Ethernet switchboard server, Enerlin'X.
IFE Ethernet switchboard server, Enerlin'X. Genuine Schneider Electric product supplied by United Force.
| Range of product | ComPact NSX100...250 · ComPact NSX400...630 · ComPact NS630b...1600 · ComPact NS1600b...3200 |
|---|---|
| Device short name | IFE |
| Product or component type | Interface module |
| Range compatibility | Masterpact MasterPact MTZ · Masterpact MasterPact NT · Masterpact MasterPact NW · ComPact ComPact NSX · ComPact ComPact NS630b...1600 · ComPact ComPact NS1600b...3200 · PowerPact PowerPact J · PowerPact PowerPact L · PowerPact PowerPact H · PowerPact PowerPact P · PowerPact PowerPact R |
| Communication network type | Ethernet, Modbus TCP/IP, HTTP, FTP, SMTP, NTP, SNMP10/100 Mbit/s on 2-port RJ45 · Universal Logic Plug on 2-port RJ45 · Modbus TCP/IP, Modbus TCP master9.6...38.4 kbauds |
| Communication gateway | Ethernet TCP/IP to Modbus |
| Web server | Embedded HTTP server |
| Mounting mode | By clips |
| Mounting support | 35 mm DIN rail |
| Control type | By software |
| [Us] rated supply voltage | 24 V DC - 20...10 % |
| Maximum supply current | 3 A |
| Current consumption | 120 mA |
| Connections - terminals | RJ45 connector |
| Product certifications | CE · GOST · cULus · FCC |
| Standards | IEC 60947-6-2 · UL 508 · UL 60950 · IEC 60950 |
| Height | 105 mm |
| Width | 72 mm |
| Depth | 71 mm |
| Product weight | 182.5 g |
| Accessory / separate part category | Spare part for Compact NS630b...1600 · Spare part for Compact NS1600b...3200 |
| IP degree of protection | Connectors: IP2X · Other parts: IP3x · Front panel: IP4X |
| Relative humidity | 5…85 % |
| Ambient air temperature for storage | -40…85 °C |
| Ambient air temperature for operation | -20…70 °C |
| Pollution degree | 3 |
| Flame retardance | V0 conforming to UL 94 · V0 conforming to IEC 60947-1 · V0 conforming to IEC 60695-2-11 |
| Shock resistance | 1000 m/s² |
| Vibration frequency | 5…8.4 Hz |
| Unit Type of Package 2 | S03 |
| Number of Units in Package 2 | 24 |
| Package 2 Height | 30.000 cm |
| Package 2 Width | 30.000 cm |
| Package 2 Length | 40.000 cm |
| Package 2 Weight | 6.609 kg |
| Warranty (in months) | 18 |
