Schneider Electric Acti9 iID residual current circuit breaker (rccb), rated 40 A. Residual current circuit breaker (RCCB), Acti9 iID, 4P, 40A, B-SI type, 30mA, double terminal.
Residual current circuit breaker (RCCB), Acti9 iID, 4P, 40A, B-SI type, 30mA, double terminal. Genuine Schneider Electric product supplied by United Force.
| Range | Acti9 |
|---|---|
| Product name | Acti9 iID |
| Product or component type | Residual current circuit breaker (RCCB) |
| Device short name | iID |
| Device application | Photovoltaic · 3P speed drive · Lift |
| Poles description | 4P |
| Neutral position | Left |
| [In] rated current | 40 A |
| Network type | AC |
| Earth-leakage sensitivity | 30 mA |
| Earth-leakage protection time delay | Instantaneous |
| Earth-leakage protection class | Type B-SI (Super Immunised) |
| Quality labels | VDE · NF · IMQ · KEMA |
| Device location in system | Outgoer · Group incomer |
| Network frequency | 50 Hz |
| [Ue] rated operational voltage | 400 V AC 50 Hz |
| Residual current tripping technology | Voltage independent |
| Rated breaking and making capacity | Idm 1500 A · Im 1500 A |
| Rated conditional short-circuit current | 10 kA |
| [Ui] rated insulation voltage | 500 V |
| [Uimp] rated impulse withstand voltage | 6 kV |
| Contact position indicator | Yes |
| Control type | Toggle |
| Local signalling | ON/OFF indication · LED (green) for presence of voltage · Trip indicator |
| Mounting mode | Clip-on |
| Mounting support | 35 mm DIN rail |
| 9 mm pitches | 8 |
| Height | 88 mm |
| Width | 72 mm |
| Depth | 73 mm |
| Product weight | 415 g |
| Colour | White (RAL 9003) |
| Mechanical durability | 20000 cycles |
| Electrical durability | 15000 cycles |
| Locking options description | Padlocking device |
| Connections - terminals | Double terminal front 1…35 mm² rigid · Double terminal front 1…25 mm² flexible · Double terminal front 1…25 mm² flexible with ferrule · Double terminal back 1…25 mm² rigid · Double terminal back 1…16 mm² flexible · Double terminal back 1…16 mm² flexible with ferrule |
| Wire stripping length | 14 mm for top or bottom connection |
| Tightening torque | 3.5 N.m top or bottom |
| Standards | EN/IEC 61008-1 · EN/IEC 61008-2-1 · IEC/EN 62423 |
| Product certifications | CCC · KC |
| IP degree of protection | IP20 conforming to IEC 60529 · IP40 (modular enclosure) conforming to IEC 60529 |
| IK degree of protection | IK05 |
| Pollution degree | 3 |
| Overvoltage category | IV |
| Electromagnetic compatibility | 8/20 µs impulse withstand, 3 kA conforming to EN/IEC 61008-1 |
