Schneider Electric oc and fault contact. Auxiliary contact, Acti9 A9A, iOF+SD, 1 NO + 1 NC, 2mA to 100mA, 24VDC, Ti24 connector on top (sold separately).
Auxiliary contact, Acti9 A9A, iOF+SD, 1 NO + 1 NC, 2mA to 100mA, 24VDC, Ti24 connector on top (sold separately). Genuine Schneider Electric product supplied by United Force.
| range of product | Acti9 |
|---|---|
| Product or component type | OC and fault contact |
| Device short name | iOF+SD 24 |
| Device application | For Smartlink interface |
| Signal contacts composition | 1 NO + 1 NC |
| [In] rated current | DC-12 2…100 mA at 24 V, DC +/- 20 % |
| 9 mm pitches | 1 |
| Standards | IEC 60947-5-4 · IEC 60947-5-1 |
| Quality labels | CE |
| Range compatibility | Acti9 iSW-NA · Acti9 iC60 · Acti9 iC65 · Acti9 iID · Acti9 ARA · Acti9 RCA · Acti9 iDPN (China version) · Acti9 iDPN Vigi · Acti9 connectors Ti24 · Acti9 iC40 · Acti9 iCVm40 · Acti9 iCVr40 · Acti9 iDDm40 |
| [Ui] rated insulation voltage | 500 V conforming to IEC 60664-1 |
| [Uimp] rated impulse withstand voltage | 6 kV conforming to IEC 60664-1 |
| Local signalling | Mechanical indicator |
| Mounting mode | Clip-on |
| Mounting support | DIN rail |
| Comb busbar and distribution block compatibility | Bottom: YES |
| Height | 88 mm |
| Width | 9 mm |
| Depth | 73.5 mm |
| Product weight | 25 g |
| Colour | White |
| Electrical durability | 20000 cycles conforming to IEC 60947-5-4 |
| Connections - terminals | Spring-loaded terminal Ti24 (top): 2 cable(s) 0.5…1.5 mm² - flexible · Spring-loaded terminal Ti24 (top): 2 cable(s) 0.5…1.5 mm² - rigid |
| Wire stripping length | 10 mm |
| Pollution degree | 2 conforming to IEC 60664-1 |
| Overvoltage category | III |
| Tropicalisation | 2 conforming to IEC 60947-5-1 |
| Relative humidity | 93 % at 40 °C |
| Ambient air temperature for operation | -25…70 °C |
| Ambient air temperature for storage | -40…85 °C |
| Unit Type of Package 2 | BB1 |
| Number of Units in Package 2 | 12 |
| Package 2 Height | 8.500 cm |
| Package 2 Width | 10.000 cm |
| Package 2 Length | 27.000 cm |
| Package 2 Weight | 523.000 g |
| Unit Type of Package 3 | S03 |
| Number of Units in Package 3 | 120 |
| Package 3 Height | 30.000 cm |
| Package 3 Width | 30.000 cm |
| Package 3 Length | 40.000 cm |
| Package 3 Weight | 5.897 kg |
| Warranty (in months) | 18 |
