Schneider Electric Enerlin'X IO i/o module. I/O (input/output) application module, Enerlin'X.
I/O (input/output) application module, Enerlin'X. Genuine Schneider Electric product supplied by United Force.
| Device short name | I/O |
|---|---|
| Product or component type | I/O module |
| Range compatibility | Masterpact MasterPact MTZ · Masterpact MasterPact NT · Masterpact MasterPact NW · ComPact ComPact NSX · ComPact ComPact NS630b...1600 · ComPact ComPact NS1600b...3200 · PowerPact PowerPact J · PowerPact PowerPact L · PowerPact PowerPact H · PowerPact PowerPact P · PowerPact PowerPact R |
| Product name | Enerlin'X IO |
| Communication network type | Universal Logic Plug on 2 RJ45 connectors |
| [Us] rated supply voltage | 24 V DC - 20...10 % |
| Current consumption | 165 mA |
| Electromagnetic compatibility | Electrostatic discharge immunity test conforming to EN/IEC 61000-4-2 · Immunity to radiated fields 10 V/m conforming to EN/IEC 61000-4-3 · Surge immunity test conforming to EN/IEC 61000-4-5 |
| Number of inputs | 6 digital · 1 analog |
| Input type | Digital at state 1: 19.8…25.2 V - DC - 6.1…8.8 mA · Digital at state 0: 0…19.8 V - DC - 0 mA |
| Number of outputs | 3 digital |
| Output type | Digital: 250 V - AC - 5 A |
| Cable length | 10 m |
| Mounting mode | By clips |
| Mounting support | 35 mm DIN rail |
| Control type | By software |
| Time delay | 0...20 s |
| Vibration frequency | 5…8.4 Hz |
| Connections - terminals | Screw terminal block |
| Product certifications | FCC · GOST · CE · cULus |
| Standards | IEC 60947-6-2 · UL 60950 · IEC 60950 · UL 508 |
| Depth | 70.6 mm |
| Height | 116 mm |
| Width | 71.7 mm |
| Product weight | 229.5 g |
| Relative humidity | 5…85 % |
| IP degree of protection | IP2X connectors: · IP4X front panel: · IP3x other parts: |
| Ambient air temperature for operation | -20…70 °C |
| Ambient air temperature for storage | -40…85 °C |
| Pollution degree | 3 |
| Flame retardance | V0 conforming to UL |
| Shock resistance | 1000 m/s² |
| Unit Type of Package 2 | S03 |
| Number of Units in Package 2 | 24 |
| Package 2 Height | 30.000 cm |
| Package 2 Width | 30.000 cm |
| Package 2 Length | 40.000 cm |
| Package 2 Weight | 7.210 kg |
| Unit Type of Package 3 | P06 |
| Number of Units in Package 3 | 192 |
| Package 3 Height | 75.000 cm |
| Package 3 Width | 60.000 cm |
| Package 3 Length | 80.000 cm |
| Package 3 Weight | 63.628 kg |
| Warranty (in months) | 18 |
