Schneider Electric TeSys GV3 motor circuit breaker, rated 25 A. Motor circuit breaker,TeSys Deca frame 3,3P,25A,magnetic,rotary handle,EverLink terminals.
Motor circuit breaker,TeSys Deca frame 3,3P,25A,magnetic,rotary handle,EverLink terminals. Genuine Schneider Electric product supplied by United Force.
| Range | TeSys Deca |
|---|---|
| Product name | TeSys GV3 |
| Product or component type | Motor circuit breaker |
| Device short name | GV3L |
| Device application | Motor protection |
| Trip unit technology | Magnetic |
| Poles description | 3P |
| Network type | AC |
| Utilisation category | Category A conforming to IEC 60947-2 · AC-3 conforming to IEC 60947-4-1 |
| Network frequency | 50/60 Hz conforming to IEC 60947-2 |
| Motor power kW | 11 kW at 400/415 V AC 50/60 Hz · 15 kW at 500 V AC 50/60 Hz · 18.5 kW at 690 V AC 50/60 Hz |
| Breaking capacity | 100 kA Icu at 230/240 V AC 50/60 Hz · 100 kA Icu at 400/415 V AC 50/60 Hz · 50 kA Icu at 440 V AC 50/60 Hz · 12 kA Icu at 500 V AC 50/60 Hz · 6 kA Icu at 690 V AC 50/60 Hz |
| [Ics] rated service short-circuit breaking capacity | 100 % at 230/240 V AC 50/60 Hz · 100 % at 400/415 V AC 50/60 Hz · 100 % at 440 V AC 50/60 Hz · 50 % at 500 V AC 50/60 Hz · 50 % at 690 V AC 50/60 Hz |
| Control type | Rotary handle |
| [In] rated current | 25 A |
| Magnetic tripping current | 350 A |
| [Ith] conventional free air thermal current | 25 A conforming to IEC 60947-2 |
| [Ue] rated operational voltage | 690 V AC 50/60 Hz conforming to IEC 60947-2 |
| [Ui] rated insulation voltage | 690 V AC 50/60 Hz conforming to IEC 60947-2 |
| [Uimp] rated impulse withstand voltage | 6 kV conforming to IEC 60947-2 |
| Suitability for isolation | Yes conforming to IEC 60947-1 |
| Power dissipation per pole | 8 W |
| Mechanical durability | 50000 cycles |
| Electrical durability | 50000 cycles for AC-3 at 415 V In |
| Rated duty | Uninterrupted conforming to IEC 60947-4-1 |
| Tightening torque | 5 N.m - on screw clamp terminal |
| Fixing mode | 35 mm symmetrical DIN rail: clipped · Panel: screwed (with 3 x M4 screws) |
| Mounting position | Horizontal · Vertical |
| Width | 55 mm |
| Height | 132 mm |
| Depth | 136 mm |
| Product weight | 0.96 kg |
| Colour | Dark grey |
| Standards | EN/IEC 60947-2 · EN/IEC 60947-4-1 · UL 60947-4-1 · CSA C22.2 No 60947-4-1 · IEC/EN 60335-1:Clause 30.2 · IEC/EN 60335-2-40:Annex JJ |
| Product certifications | CCC · UL · CSA · EAC · LROS (Lloyds register of shipping) · BV · ABS · DNV-GL · UKCA |
| IP degree of protection | IP20 conforming to IEC 60529 |
| Climatic withstand | conforming to IACS E10 |
| Ambient air temperature for storage | -40…80 °C |
| Fire resistance | 960 °C conforming to IEC 60695-2-11 |
| Ambient air temperature for operation | -20…60 °C |
| Mechanical robustness | Shocks: 15 Gn for 11 ms contactor open · Shocks: 30 Gn for 11 ms contactor closed · Vibrations: 4 Gn, 5...300 Hz |
| Operating altitude | 3000 m |
| Unit Type of Package 2 | S06 |
| Number of Units in Package 2 | 60 |
| Package 2 Height | 75.000 cm |
