Schneider Electric base unit. base unit, Harmony GTU, Open BOX Windows 10, Universal Panel, with HMI software installed.
base unit, Harmony GTU, Open BOX Windows 10, Universal Panel, with HMI software installed. Genuine Schneider Electric product supplied by United Force.
| Range of product | Harmony GTU |
|---|---|
| Product or component type | Base unit |
| Device short name | Open Box |
| Range compatibility | Harmony GTU |
| [Us] rated supply voltage | 12...24 V DC power supply |
| Integrated connection type | Ethernet TCP/IP with 2 RJ45 · COM1 serial link RJ45 RS485, transmission rate: 2400...115200 bps · COM2 serial link SUB-D 9 RS232C/RS422/RS485, transmission rate: 2400...115200 bps · Auxiliary port terminal block · USB 2.0 port mini B USB · DVI-D video port DVI-D · Microphone mini-jack · USB 2.0 port with 3 USB type A |
| Communication port protocol | Modbus · Modbus TCP/IP · Uni-Telway |
| Software package | Vijeo Designer |
| Processor name | ARM Cortex-A9 |
| Data storage equipment | 32 GB CFast card |
| Port Ethernet | 10BASE-T/100BASE-TX/1000BASE-T |
| Memory description | 512 KB NVRAM backup memory · 4 GB RAM internal |
| Number of slots | 1 slot(s) for SD card · 2 slot(s) for Cfast card |
| Realtime clock | Built-in |
| Local signalling | LED, multi-colour for status |
| Type of cooling | Natural convection |
| Width | 188 mm |
| Height | 131 mm |
| Depth | 45 mm |
| Product weight | 0.9 kg |
| Standards | CSA C22.2 No 142 · ANSI/ISA 12-12-01 · UL 508 · Class I division 2 CSA C22.2 No 213 · IEC 61132-2 |
| Product certifications | CE · CULus · ATEX · IEC-Ex · RCM · DNV-GL · KC · CUL · EAC · UKCA · UKEX |
| Ambient air temperature for operation | 0…60 °C |
| Ambient air temperature for storage | -20…60 °C |
| Pollution degree | 2 conforming to IEC 61131-2 ed.3 |
| Relative humidity | 10…90 % non-condensing |
| Operating altitude | 2000 |
| Vibration resistance | 3.5 mm constant amplitude (f = 5…9 Hz) conforming to IEC 61131-2 · 9.8 m/s² (f = 9…150 Hz) conforming to IEC 61131-2 |
| Shock resistance | 147 m/s² conforming to IEC 61131-2 |
| Electromagnetic compatibility | Electrostatic discharge immunity test level 3 conforming to IEC 61000-4-2 |
| Unit Type of Package 2 | S04 |
| Number of Units in Package 2 | 4 |
| Package 2 Height | 30.000 cm |
| Package 2 Width | 40.000 cm |
| Package 2 Length | 60.000 cm |
| Package 2 Weight | 6.055 kg |
| Warranty (in months) | 18 |
