Schneider Electric TeSys LRD · TeSys Deca differential thermal overload relay, rated 5 A. Thermal overload relay,TeSys Deca,1.6-2.5A,1NO+1NC,class 10A,spring terminal.
Thermal overload relay,TeSys Deca,1.6-2.5A,1NO+1NC,class 10A,spring terminal. Genuine Schneider Electric product supplied by United Force.
| Range | TeSys · TeSys Deca |
|---|---|
| Product name | TeSys LRD · TeSys Deca |
| Product or component type | Differential thermal overload relay |
| Device short name | LRD |
| Relay application | Motor protection |
| Product compatibility | LC1D09 · LC1D32 · LC1D25 · LC1D38 · LC1D12 · LC1D18 |
| Network type | DC · AC |
| Thermal overload class | Class 10A conforming to IEC 60947-4-1 |
| Thermal protection adjustment range | 1.6…2.5 A |
| [Ui] rated insulation voltage | Power circuit: 600 V conforming to CSA · Power circuit: 600 V conforming to UL · Power circuit: 690 V conforming to IEC 60947-4-1 |
| Network frequency | 0...400 Hz |
| Mounting support | Plate, with specific accessories · Rail, with specific accessories · Under contactor |
| Tripping threshold | 1.14 +/- 0.06 Ir conforming to IEC 60947-4-1 |
| Auxiliary contact composition | 1 NO + 1 NC |
| [Ith] conventional free air thermal current | 5 A for signalling circuit |
| Permissible current | 3 A at 120 V AC-15 for signalling circuit · 0.22 A at 125 V DC-13 for signalling circuit |
| [Ue] rated operational voltage | 690 V AC 0...400 Hz for power circuit conforming to IEC 60947-4-1 |
| Associated fuse rating | 4 A gG for signalling circuit · 4 A BS for signalling circuit |
| [Uimp] rated impulse withstand voltage | 6 kV |
| Phase failure sensitivity | Tripping current 130 % of Ir on two phase, the last one at 0 |
| Control type | Red push-button: stop · Blue push-button: reset |
| Temperature compensation | -20…60 °C |
| Connections - terminals | Control circuit: spring terminals 1 cable(s) 1…2.5 mm² solid without cable end · Control circuit: spring terminals 1 cable(s) 1…2.5 mm² flexible without cable end · Power circuit: spring terminals 1 cable(s) 1.5…4 mm² flexible without cable end · Power circuit: spring terminals 1 cable(s) 1.5…4 mm² flexible with cable end |
| Height | 93 mm |
| Width | 45 mm |
| Depth | 72 mm |
| Product weight | 0.14 kg |
| Climatic withstand | conforming to IACS E10 |
| IP degree of protection | IP20 conforming to IEC 60529 |
| Ambient air temperature for operation | -20…60 °C without derating conforming to IEC 60947-4-1 |
| Ambient air temperature for storage | -60…70 °C |
| Flame retardance | V1 conforming to UL 94 |
| Mechanical robustness | Vibrations: 6 Gn conforming to IEC 60068-2-6 · Shocks: 15 Gn for 11 ms conforming to IEC 60068-2-7 |
| Dielectric strength | 1.89 kV at 50 Hz conforming to IEC 60947-1 |
| Standards | EN/IEC 60947-4-1 · EN/IEC 60947-5-1 · UL 60947-4-1 · UL 60947-5-1 · CSA C22.2 No 60947-4-1 · CSA C22.2 No 60947-5-1 · GB/T 14048.4 · GB/T 14048.5 · EN 50495 |
| Product certifications | IEC · UL · CSA · CCC · EAC · BV · RINA · DNV-GL · LROS (Lloyds register of shipping) · ATEX INERIS · UKCA |
| Unit Type of Package 2 | S02 |
| Number of Units in Package 2 | 23 |
| Package 2 Height | 15 cm |
| Package 2 Width | 30 cm |
| Package 2 Length | 40 cm |
| Package 2 Weight | 4.698 kg |
| Warranty (in months) | 18 |
