Schneider Electric PowerLogic PM8000 power meter, rated 1 A. Power quality meter, PowerLogic PM8000, Standard, integrated display, 512 MB, 256 s/c.
Power quality meter, PowerLogic PM8000, Standard, integrated display, 512 MB, 256 s/c. Genuine Schneider Electric product supplied by United Force.
| Range | PowerLogic |
|---|---|
| Product name | PowerLogic PM8000 |
| Product or component type | Power meter |
| Device short name | PM8240 |
| Market segment | Buildings large building cost management: billing: sub feeder · Buildings small building network management: main incomer · Buildings medium building network management: main incomer · Buildings large building network management: main incomer · Buildings large building network management: sub feeder · Buildings multi-site network management: main incomer · Buildings multi-site network management: sub feeder · Data center network management: main incomer · Data center network management: sub feeder · Healthcare network management: main incomer · Healthcare network management: sub feeder · Industry network management: main incomer · Industry network management: sub feeder · Utility: sub feeder |
| model type | Standard |
| Power quality analysis | conforming to EN 50160: 2010 compliance report · conforming to IEEE 519: 2014 compliance report · conforming to IEC 61000-4-30: class S power quality measurement · up to the 63rd harmonic · harmonic distortion · waveform capture · voltage sag and swell detection · programmablity (logic and math functions) · conforming to IEC 62586 power quality monitoring · disturbance direction detection · rapid voltage change |
| Device application | Power monitoring · WAGES metering |
| Type of measurement | Current · Voltage · Frequency · Active and reactive power total · Apparent power total · Power factor total · Active and reactive power per phase, rms · Apparent power per phase, rms · Power factor per phase, rms |
| supply voltage | 90...415 V AC 45...65 Hz +/- 10 % · 110...415 V DC +/- 10 % |
| Network frequency | 50 Hz · 60 Hz |
| [In] rated current | 1 A · 5 A · 10 A |
| Poles description | 3P + N · 3P · 1P + N |
| Power consumption in VA | 16 VA at 230 V AC |
| Display type | Colour TFT LCD |
| Display resolution | 320 x 240 pixels QVGA |
| Sampling rate | 256 samples/cycle |
| Measurement current | 50…10000 mA |
| Analogue input type | Voltage (impedance 5 MOhm) · Current (impedance 0.3 mOhm) |
| Measurement voltage | 57…400 V AC 42...69 Hz between phase and neutral · 100…690 V AC 42...69 Hz between phases |
| Frequency measurement range | 42…69 Hz |
| Number of inputs | 3 digital 30 V AC · 3 digital 60 V DC |
| Measurement accuracy | Current +/- 0.1 % · Voltage +/- 0.1 % · Active energy +/- 0.2 % |
| Accuracy class | Class 0.2S active energy conforming to IEC 62053-22 · Class 0.2 active energy conforming to ANSI C12.20 · Class 0.2 active power conforming to IEC 61557-12 · Class 0.5S reactive energy conforming to IEC 62053-24 · Class 0.5 power factor conforming to IEC 61557-12 · Class 0.2 voltage conforming to IEC 61557-12 · Class 0.2 current conforming to IEC 61557-12 |
| Number of outputs | 1 pulse |
| Information displayed | Voltage · Current · Frequency · Power · Energy consumption · Harmonic distortion |
| Communication port protocol | Modbus RTU at 115 kbauds - 2-wire · ION at 115 kbauds - 2-wire · DNP3 · IEC 61850 · Modbus TCP/IP · Ethernet Modbus TCP/IP daisy chain at 10/100 Mbit/s · RSTP 801.1d 2004 |
| Communication port support | ETHERNET · Screw terminal block: RS485 |
| Communication network type | IPv6 (internet protocol) |
| Data recording | Min/max of instantaneous values · Waveform logs · Sequence of event recording · Time stamping · Alarm logs · Trending/forecasting · Sag and swell logs · Harmonics logs · GPS synchronisation · Data logs · Event logs · 50 data recorders |
| Memory capacity | 512 MB |
| Web services | Customizable home page · File upload/download via FTP · File upload/download via SFTP · Web server · Alarm notification by e-mail · Viewing of captured waveform (FTP) · Viewing of captured waveform (web) · HTTPS server |
| Communication service | SMTP e-mail notification · RSTP support · NTP time synchronization · DHCP · PTP time synchronization |
| Cybersecurity | Enable/disable communication ports · Password protection · Syslog protocol support · Robust security logs · Port hardening |
| Mounting mode | Flush-mounted |
| Mounting support | Framework |
| Installation category | III |
| Safety Construction | III400…690 V conforming to IEC 61010-1:ed. 3 · III400…690 V conforming to EN 61010-1:ed. 3 · III347…600 V conforming to UL 61010-1:ed. 3 · III347…600 V conforming to CSA C22.2 No 61010-1:ed. 3 |
| Standards | IEC 61557-12 · IEC 62052-11 · IEC 62053-24 · IEC 62053-22 · IEEE 1588 · IEC 62586-2 · IEC 61326-1 |
| Product certifications | CE · CULus · N998 |
| Width | 96 mm |
| Depth | 77.5 mm |
| Height | 96 mm |
| Product weight | 581 g |
| Electromagnetic compatibility | Electrostatic discharge conforming to IEC 61000-4-2 · Radiated radio-frequency electromagnetic field immunity test conforming to IEC 61000-4-3 · Electrical fast transient/burst immunity test conforming to IEC 61000-4-4 · Surge immunity test conforming to IEC 61000-4-5 · Conducted RF disturbances conforming to IEC 61000-4-6 · Magnetic field at power frequency conforming to IEC 61000-4-8 · Voltage dips and interruptions immunity test conforming to IEC 61000-4-11 · Immunity to impulse waves conforming to IEC 61000-4-12 · Conducted and radiated emissions conforming to EN 55022 · Conducted and radiated emissions conforming to EN 55011 · Conducted and radiated emissions conforming to FCC part 15 · Conducted and radiated emissions conforming to ICES-003 · Conducted RF disturbances (2...150 Hz) conforming to CLC/TR 50579 · Surge withstand conforming to IEEE C37.90.1 |
