Schneider Electric pressure transmitter sensor. EP Series Differential Pressure/Air Velocity Transducer, Panel Mounting, 0-10 in. WC/0-2500Pa.
EP Series Differential Pressure/Air Velocity Transducer, Panel Mounting, 0-10 in. WC/0-2500Pa. Genuine Schneider Electric product supplied by United Force.
| Range of product | TAC |
|---|---|
| Product or component type | Pressure transmitter sensor |
| Sensor model | EPP302 |
| Type of measurement | Differential pressure |
| Device application | Duct pressure monitoring · Filter monitoring · Fan monitoring · VAV control · Air velocity monitoring |
| Burst pressure | 5 psid (34.5 kPa) |
| Product certifications | CE |
| Controlled fluid | Air · Gas |
| Fitting size | 6 mm (0.24") |
| Fitting type | Male |
| IP degree of protection | IP65 |
| location | Plant room |
| Mounting support | Panel |
| Depth | 42 mm |
| Height | 112 mm |
| Probe diameter | 7 mm |
| Probe length | 188 mm |
| Product weight | 0.125 kg |
| Width | 88 mm |
| Pressure measurement drift | Less than 0.5 % |
| Pressure measurement range | 0...1" W.C. (0...250 Pa) · 0...2.5" W.C. (0...500 Pa) · 0...5" W.C. (0...1000 Pa) · 0...10" W.C. (0...2500 Pa) |
| Ambient air temperature for operation | -20…60 °C |
| Wiring technique | 3-wire |
| Standards | EN 61000-6-3 · EN 61000-6-1 · EN 61326-1 · EN 61326-2-1 |
| Calibration certificate | None |
| Local signalling | Red/green/blue LED |
| [Us] rated supply voltage | 12...30 V DC · 24 V AC |
| Mounting mode | Panel |
| Output type | Analog 3-wire 4...20 mA · Analog 0...5 V DC · Analog 0...10 V DC |
| Accuracy | +/- 1 % FS |
| Material | ABS thermoplastic: enclosure · Brass: fitting |
| Electrical connection | - 22 AWG |
| Display type | LCD |
| Unit Type of Package 2 | BB1 |
| Number of Units in Package 2 | 40 |
| Package 2 Height | 35.000 cm |
| Package 2 Width | 34.000 cm |
| Package 2 Length | 65.000 cm |
| Package 2 Weight | 9.044 kg |
| Warranty (in months) | 18 |
