Schneider Electric TeSys D · TeSys Deca reversing contactor, rated 9 A. Reversing Contactor, TeSys Deca, 3P(3NO), AC-3, <=440V, 9A, 110V AC 50/60Hz coil, screw clamp terminals.
Reversing Contactor, TeSys Deca, 3P(3NO), AC-3, <=440V, 9A, 110V AC 50/60Hz coil, screw clamp terminals. Genuine Schneider Electric product supplied by United Force.
| Range | TeSys · TeSys Deca |
|---|---|
| Product name | TeSys D · TeSys Deca |
| Product or component type | Reversing contactor |
| Device short name | LC2D |
| Contactor application | Resistive load · Motor control |
| Utilisation category | AC-1 · AC-3 · AC-3e |
| Device presentation | Preassembled with reversing power busbar |
| Poles description | 3P |
| power pole contact composition | 3 NO |
| [Ue] rated operational voltage | Power circuit: <= 690 V AC 25...400 Hz · Power circuit: <= 300 V DC |
| [Ie] rated operational current | 9 A (at <60 °C) at <= 440 V AC AC-3 for power circuit · 25 A (at <60 °C) at <= 440 V AC AC-1 for power circuit |
| Motor power kW | 2.2 kW at 220...230 V AC 50...60 Hz · 4 kW at 380...400 V AC 50...60 Hz · 4 kW at 415 V AC 50...60 Hz · 4 kW at 440 V AC 50...60 Hz · 5.5 kW at 500 V AC 50...60 Hz · 5.5 kW at 660...690 V AC 50...60 Hz |
| Motor power hp | 0.5 hp at 115 V AC 60 Hz for 1 phase motors · 1 hp at 230/240 V AC 60 Hz for 1 phase motors · 2 hp at 200/208 V AC 60 Hz for 3 phases motors · 2 hp at 230/240 V AC 60 Hz for 3 phases motors · 5 hp at 460/480 V AC 60 Hz for 3 phases motors · 7.5 hp at 575/600 V AC 60 Hz for 3 phases motors |
| Control circuit type | AC at 50/60 Hz |
| [Uc] control circuit voltage | 110 V AC 50/60 Hz |
| Auxiliary contact composition | 1 NO + 1 NC |
| [Uimp] rated impulse withstand voltage | 6 kV conforming to IEC 60947 |
| Overvoltage category | III |
| [Ith] conventional free air thermal current | 10 A (at 60 °C) for signalling circuit · 25 A (at 60 °C) for power circuit |
| Irms rated making capacity | 250 A at 440 V for power circuit conforming to IEC 60947 · 140 A AC for signalling circuit conforming to IEC 60947-5-1 · 250 A DC for signalling circuit conforming to IEC 60947-5-1 |
| Rated breaking capacity | 250 A at 440 V for power circuit conforming to IEC 60947 |
| [Icw] rated short-time withstand current | 30 A 40 °C - 10 min for power circuit · 61 A 40 °C - 1 min for power circuit · 105 A 40 °C - 10 s for power circuit · 210 A 40 °C - 1 s for power circuit · 100 A - 1 s for signalling circuit · 120 A - 500 ms for signalling circuit · 140 A - 100 ms for signalling circuit |
| Associated fuse rating | 25 A gG at <= 690 V coordination type 1 for power circuit · 20 A gG at <= 690 V coordination type 2 for power circuit · 10 A gG for signalling circuit conforming to IEC 60947-5-1 |
| Average impedance | 2.5 mOhm - Ith 25 A 50 Hz for power circuit |
| [Ui] rated insulation voltage | Power circuit: 690 V conforming to IEC 60947-4-1 · Power circuit: 600 V CSA certified · Power circuit: 600 V UL certified · Signalling circuit: 690 V conforming to IEC 60947-1 · Signalling circuit: 600 V CSA certified · Signalling circuit: 600 V UL certified |
| Electrical durability | 0.6 Mcycles 25 A AC-1 at Ue <= 440 V · 2 Mcycles 9 A AC-3 at Ue <= 440 V |
| Power dissipation per pole | 0.2 W AC-3 · 1.56 W AC-1 · 0.2 W AC-3e |
| Front cover | With |
| Interlocking type | Mechanical |
| Mounting support | Rail · Plate |
| Standards | CSA C22.2 No 14 · EN 60947-4-1 · EN 60947-5-1 · IEC 60947-4-1 · IEC 60947-5-1 · UL 60335-2-40:Annex JJ · IEC 60335-1 |
| Product certifications | DNV · CSA · CCC · UL · GL · LROS (Lloyds register of shipping) · BV · RINA · GOST · UKCA |
| Connections - terminals | Power circuit: screw clamp terminals 1 cable(s) 1…4 mm²flexible without cable end · Power circuit: screw clamp terminals 2 cable(s) 1…4 mm²flexible without cable end · Power circuit: screw clamp terminals 1 cable(s) 1…4 mm²flexible with cable end · Power circuit: screw clamp terminals 2 cable(s) 1…2.5 mm²flexible with cable end · Power circuit: screw clamp terminals 1 cable(s) 1…4 mm²solid · Power circuit: screw clamp terminals 2 cable(s) 1…4 mm²solid · Control circuit: screw clamp terminals 1 cable(s) 1…4 mm²flexible without cable end · Control circuit: screw clamp terminals 2 cable(s) 1…4 mm²flexible without cable end · Control circuit: screw clamp terminals 1 cable(s) 1…4 mm²flexible with cable end · Control circuit: screw clamp terminals 2 cable(s) 1…2.5 mm²flexible with cable end · Control circuit: screw clamp terminals 1 cable(s) 1…4 mm²solid · Control circuit: screw clamp terminals 2 cable(s) 1…4 mm²solid |
| Tightening torque | Power circuit: 1.7 N.m - on screw clamp terminals - with screwdriver flat Ø 6 mm · Power circuit: 1.7 N.m - on screw clamp terminals - with screwdriver Philips No 2 · Control circuit: 1.7 N.m - on screw clamp terminals - with screwdriver flat Ø 6 mm · Control circuit: 1.7 N.m - on screw clamp terminals - with screwdriver Philips No 2 · Control circuit: 1.7 N.m - on screw clamp terminals - with screwdriver pozidriv No 2 · Power circuit: 2.5 N.m - on screw clamp terminals - with screwdriver pozidriv No 2 |
| Operating time | 12...22 ms closing · 4...19 ms opening |
| Safety reliability level | B10d = 1369863 cycles contactor with nominal load conforming to EN/ISO 13849-1 · B10d = 20000000 cycles contactor with mechanical load conforming to EN/ISO 13849-1 |
| Mechanical durability | 15 Mcycles |
| Maximum operating rate | 3600 cyc/h 60 °C |
| Coil technology | Without built-in suppressor module |
| Control circuit voltage limits | 0.3...0.6 Uc (-40…70 °C):drop-out AC 50/60 Hz · 0.8...1.1 Uc (-40…60 °C):operational AC 50 Hz · 0.85...1.1 Uc (-40…60 °C):operational AC 60 Hz · 1...1.1 Uc (60…70 °C):operational AC 50/60 Hz |
| Inrush power in VA | 70 VA 60 Hz cos phi 0.75 (at 20 °C) · 70 VA 50 Hz cos phi 0.75 (at 20 °C) |
| Hold-in power consumption in VA | 7.5 VA 60 Hz cos phi 0.3 (at 20 °C) · 7 VA 50 Hz cos phi 0.3 (at 20 °C) |
| Heat dissipation | 2…3 W at 50/60 Hz |
| Auxiliary contacts type | type mechanically linked 1 NO + 1 NC conforming to IEC 60947-5-1 · type mirror contact 1 NC conforming to IEC 60947-4-1 |
| Signalling circuit frequency | 25...400 Hz |
