Schneider Electric PanelSeT S3D. Wall mounted steel enclosure, PanelSeT S3D, double plain door, without mounting plate, 1400x1000x300mm, IP55, IK10.
Wall mounted steel enclosure, PanelSeT S3D, double plain door, without mounting plate, 1400x1000x300mm, IP55, IK10. Genuine Schneider Electric product supplied by United Force.
Technical specifications
| Range | PanelSeT |
|---|
| Product name | PanelSeT S3D |
|---|
| Application | Multi-purpose |
|---|
| Category | Compact enclosure |
|---|
| Enclosure nominal height | 1400 mm |
|---|
| Enclosure nominal width | 1000 mm |
|---|
| Enclosure nominal depth | 300 mm |
|---|
| Door type | Plain |
|---|
| Mounting plate description | Without mounting plate |
|---|
| Type of gland plate | Standard |
|---|
| Installation accessory type | Wall-mounting |
|---|
| Device composition | 1 body · 2 cable gland plate · 1 lock · 2 door |
|---|
| body type | Gutter-shaped front rail double sheet thickness · Single piece body |
|---|
| Number of doors | Front face: 2 door(s) |
|---|
| Door opening side | Reversible (120 °) |
|---|
| Lock type | 3 points lock, 3 mm double-bar |
|---|
| Accessibility for operation | Front |
|---|
| Removable parts | Door by hinges · Cable gland plate by screws |
|---|
| Material | Steel |
|---|
| Surface finish | Epoxy-polyester powder |
|---|
| Colour | Grey (RAL 7035) |
|---|
| Standards | IEC 62208 · UL · CUL |
|---|
| Product certifications | GL · DNV · BV · UL · cUL |
|---|
| Product weight | 84 kg |
|---|
| Electromagnetic compatibility | Electromagnetic field immunity test |
|---|
| IK degree of protection | IK10 conforming to IEC 62262 |
|---|
| IP degree of protection | IP55 conforming to IEC 60529 |
|---|
| Warranty (in months) | 18 |
|---|
