Schneider Electric PanelSeT suitable enclosure. Floor standing modular electrical enclosure, PanelSeT SFN, decarbonized steel, mounting plate, 1800x600x600mm, IP55.
Floor standing modular electrical enclosure, PanelSeT SFN, decarbonized steel, mounting plate, 1800x600x600mm, IP55. Genuine Schneider Electric product supplied by United Force.
Technical specifications
| Range | PanelSeT |
|---|
| Extended range | PanelSeT SFN |
|---|
| Application | Multi-purpose |
|---|
| Product or component type | Suitable enclosure |
|---|
| Enclosure nominal height | 1800 mm |
|---|
| Enclosure nominal width | 600 mm |
|---|
| Enclosure nominal depth | 600 mm |
|---|
| Enclosure mounting | Floor-standing |
|---|
| Device composition | 2 sliding rails · 4 mounting plate quick-fixing brackets · 1 structure · 1 door · 1 locking system with handle: door · 1 rear panel · 1 roof · 1 mounting plate |
|---|
| Structure type | Vertical uprights joined with top and bottom frames · Perforated structure with a pitch of 25 mm · Panels and doors built into the structure · Formed from a single section |
|---|
| Door opening side | Reversible (120 °) |
|---|
| Door type | Plain front |
|---|
| Mounting plate description | Plain |
|---|
| Type of gland plate | Without gland plate |
|---|
| Lock type | 4 points lock, handle with 5 mm double bar insert front door |
|---|
| Number of doors | Front: 1 door(s) |
|---|
| Accessibility for operation | Rear · Front · Sides of enclosure |
|---|
| Removable parts | Door by screws hinge · Mounting plate by screws mounting plate bracket · Rear panel by screws · Roof by screws · Mounting plate bracket by screws · Sliding rail by screws |
|---|
| Material | Frame: galvanised steel · Uprights: galvanised steel · Door: sheet steel · Panels: sheet steel · Hinge: zamak · Handle: polyamide 6 with 30 % fibre glass |
|---|
| Surface finish | Epoxy-polyester powder |
|---|
| Colour | Enclosure: grey (RAL 7035) · Handle: black (RAL 9005) |
|---|
| Product weight | 85.7 kg |
|---|
| Standards | IEC 62208 · UL · CUL |
|---|
| NEMA degree of protection | NEMA 3R/12 |
|---|
| IP degree of protection | IP55 conforming to IEC 60529 |
|---|
| IK degree of protection | IK10 conforming to IEC 62262 |
|---|
| Warranty (in months) | 18 |
|---|
