Schneider Electric PanelSeT suitable enclosure. Floor standing modular electrical enclosure, PanelSeT SFN, decarbonized steel, plate, 1800x1200x600mm, 2 doors, IP55.
Floor standing modular electrical enclosure, PanelSeT SFN, decarbonized steel, plate, 1800x1200x600mm, 2 doors, IP55. Genuine Schneider Electric product supplied by United Force.
Technical specifications
| Range | PanelSeT |
|---|
| Extended range | PanelSeT SFN |
|---|
| Application | Multi-purpose |
|---|
| Product or component type | Suitable enclosure |
|---|
| Enclosure nominal height | 1800 mm |
|---|
| Enclosure nominal width | 1200 mm |
|---|
| Enclosure nominal depth | 600 mm |
|---|
| Enclosure mounting | Floor-standing |
|---|
| Device composition | 2 sliding rails · 4 mounting plate quick-fixing brackets · 1 structure: left door · 1 rear panel: right door · 1 roof · 1 mounting plate · 2 door · 1 locking system with handle · 1 locking bar system 4 points: right door · 1 locking bar system 2 points: left door |
|---|
| Structure type | Perforated structure with a pitch of 25 mm · Formed from a single section · Panels and doors built into the structure · Vertical uprights joined with top and bottom frames |
|---|
| Door opening side | Left (120 °) · Right (120 °) |
|---|
| Door type | Plain front |
|---|
| Mounting plate description | Plain |
|---|
| Type of gland plate | Without gland plate |
|---|
| Lock type | 4 points lock, handle with 5 mm double bar insert front right door |
|---|
| Number of doors | Front face: 2 door(s) |
|---|
| Accessibility for operation | Rear · Sides of enclosure · Front |
|---|
| Removable parts | Door by screws hinge · Mounting plate by screws mounting plate bracket · Rear panel by screws · Roof by screws · Mounting plate bracket by screws · Sliding rail by screws |
|---|
| Material | Frame: galvanised steel · Uprights: galvanised steel · Door: sheet steel · Panels: sheet steel · Hinge: zamak · Handle: polyamide 6 with 30 % fibre glass |
|---|
| Surface finish | Epoxy-polyester powder |
|---|
| Colour | Enclosure: grey (RAL 7035) · Handle: black (RAL 9005) |
|---|
| Product weight | 148.5 kg |
|---|
| Standards | IEC 62208 · UL · CUL |
|---|
| NEMA degree of protection | NEMA 3R/12 |
|---|
| IP degree of protection | IP55 conforming to IEC 60529 |
|---|
| IK degree of protection | IK10 conforming to IEC 62262 |
|---|
| Warranty (in months) | 18 |
|---|
