Schneider Electric PanelSeT SM compact enclosure. PanelSeT SM compact enclosure without mounting plate - 1600x800x400 mm.
PanelSeT SM compact enclosure without mounting plate - 1600x800x400 mm. Genuine Schneider Electric product supplied by United Force.
| Range | PanelSeT |
|---|---|
| Product name | PanelSeT SM |
| Product or component type | Compact enclosure |
| Application | Multi-purpose |
| Installation accessory type | Floor-standing |
| Device composition | 1 body · 1 cable gland plate · 1 locking system with handle: door · 4 mounting plate bracket · 1 door |
| Removable parts | Door by screws hinge · Mounting plate bracket by screws |
| Enclosure nominal height | 1600 mm |
| Enclosure nominal width | 800 mm |
| Enclosure nominal depth | 400 mm |
| Number of doors | Front: 1 door(s) |
| Door opening side | Reversible (120 °) |
| Door type | Plain |
| Lock type | 4 points lock, handle with 5 mm double bar insert |
| Body type | Front part forming a rigid frame with welded corners · Single piece body with welded rear panel |
| Mounting plate description | Without mounting plate |
| Type of gland plate | Standard |
| cable entry | 1 entry |
| Material | Body: sheet steel · Door: sheet steel · Hinge: zamak |
| Surface finish | Epoxy-polyester powder |
| Colour | Enclosure: grey (RAL 7035) · Handle: black (RAL 9005) |
| Accessibility for operation | Front |
| Product weight | 76.5 kg |
| Standards | IEC 62208 |
| Product certifications | DNV · UL · BV |
| IK degree of protection | IK10 conforming to IEC 62262 · conforming to UL · conforming to cUL |
| IP degree of protection | IP55 conforming to IEC 60529 |
| Unit Type of Package 2 | PAL |
| Number of Units in Package 2 | 2 |
| Package 2 Height | 173.000 cm |
| Package 2 Width | 85.000 cm |
| Package 2 Length | 98.000 cm |
| Package 2 Weight | 155.000 kg |
| Warranty (in months) | 18 |
