Schneider Electric field controller. Plantroom Controller, SpaceLogic MP-C-15A, BACnet/IP, 15pts: 8 UI/Os (Ub), 6 Triac Outs, 1 HP Relay Out, Smoke Ctrl.
Plantroom Controller, SpaceLogic MP-C-15A, BACnet/IP, 15pts: 8 UI/Os (Ub), 6 Triac Outs, 1 HP Relay Out, Smoke Ctrl. Genuine Schneider Electric product supplied by United Force.
Technical specifications
| Maximum number of I/O expansion module | 3 |
|---|
| Topology | Star · Daisy chain · Rapid Spanning Tree Protocol (RSTP) |
|---|
| Width | 153 mm |
|---|
| Mounting mode | DIN rail mount · Panel-mounted |
|---|
| Product certifications | RCM · CE · cUL listed · UL listed |
|---|
| Power consumption in W | 12 W |
|---|
| Power consumption in VA | 22 VA |
|---|
| Clock drift | +/- 1 min/month |
|---|
| Device application | Low voltage fan coil |
|---|
| Product or component type | Field controller |
|---|
| Device short name | MP-C-15A-SMK |
|---|
| Function available | Programmable · Smart sensor input · UL smoke control |
|---|
| Model | MP-C-15A-SMK |
|---|
| Network frequency | 50 Hz · 60 Hz |
|---|
| Ambient air temperature for storage | -40…70 °C |
|---|
| IP degree of protection | IP20 |
|---|
| Input/output type | 8 universal I/O |
|---|
| Input voltage | -0.5...24 V DC for universal input |
|---|
| Memory type | 123 kB backup · 32 MB flash · 128 MB RAM |
|---|
| Communication port support | ETHERNET 10/100BASE-TX |
|---|
| [Us] rated supply voltage | 24 V AC +/- 20 % · 24...30 V DC · 21...33 V DC |
|---|
| Number of outputs | 6 triac output · 1 relay output |
|---|
| Depth | 64 mm |
|---|
| Protection type | MOV suppression · Internal fuse |
|---|
| Output voltage | 250 V AC,12 A for high power relay output · 24 V DC,12 A for high power relay output · -0.5...24 V DC for universal output · 24 V AC for triac output |
|---|
| Output current | 0.5 A max triac output |
|---|
| Number of port | 2, connector type: RJ45 · 1, connector type: USB type A female · 1, connector type: USB device port Mini-B |
|---|
| Backup time | 7 days |
|---|
| Flame retardance | UL94-5V |
|---|
| Communication port protocol | BACnet IP |
|---|
| Standards | UL 916 · ICES-003 · UL 864 · EN 61000-6-2 · EN 50491-5-3 · EN 60730-1 · EN 60730-2-11 · EN 50491-3 · EN 61000-6-3 · EN 50491-5-2 · FCC part 15 Subpart B class B |
|---|
| Range compatibility | SpaceLogic IP controller |
|---|
| Warranty (in months) | 18 |
|---|
