Schneider Electric TeSys VARIO enclosed switch-disconnector, rated 57 A. Enclosed switch disconnector,TeSys Control,for ON/OFF, 63A, 3P, IP65.
Enclosed switch disconnector,TeSys Control,for ON/OFF, 63A, 3P, IP65. Genuine Schneider Electric product supplied by United Force.
| Range | TeSys |
|---|---|
| Product name | TeSys VARIO |
| Device short name | VBF |
| Device application | Preventive maintenance |
| Product or component type | Enclosed switch-disconnector |
| Performance level | High performance |
| Poles description | 3P |
| Control type | Rotary handle |
| Handle colour | Black |
| Handle front plate colour | Black |
| Rotary handle padlocking | 1 to 3 padlocks 4…8 mm |
| Marking | 0 - 1 |
| [Ue] rated operational voltage | 690 V AC |
| [Uimp] rated impulse withstand voltage | 8 kV |
| [Ithe] conventional enclosed thermal current | 63 A |
| [Ie] rated operational current | 57 A (AC-23A) at 400 V |
| Rated operational power in W | 30 kW at 400 V (AC-23) · 22 kW at 400 V (AC-3) |
| Intermittent duty class | 30 |
| Making capacity ( I rms) | 800 A at 400 V AC-21A · 800 A at 400 V AC-22A · 800 A at 400 V AC-23A |
| [Icm] rated short-circuit making capacity | 2.1 kA at 400 V at Ipeak |
| [Icw] rated short-time withstand Rms current | 960 A at 400 V duration: 1 s |
| Rated conditional short-circuit current | 10 kA at 400 V - associated fuse 80 A aM · 10 kA at 400 V - associated fuse 80 A gG |
| Breaking capacity | 640 A at 400 V (AC-21A) · 640 A at 400 V (AC-22A) · 640 A at 400 V (AC-23A) |
| Mechanical durability | 30000 cycles |
| Electrical durability | 30000 cycles AC-21 · 30000 cycles DC-1...5 |
| Environmental characteristic | Standard environment |
| Suitability for isolation | Yes |
| Connections - terminals | Screw clamp terminals16 mm² - flexible - with cable end · Screw clamp terminals25 mm² - solid |
| Tightening torque | 4 N.m - on screw clamp terminals |
| Fire resistance | 960 °C conforming to IEC 60595-2-1 |
| handle front plate dimension | 60 x 60 mm |
| Height | 180 mm |
| Width | 157 mm |
| Depth | 152 mm |
| Product weight | 0.93 kg |
| Standards | IEC 60947-4-1 · IEC 60204 |
| Protective treatment | TC |
| IP degree of protection | IP65 conforming to IEC 60529 |
| Mechanical robustness | Vibrations 10...150 Hz (1 gn) conforming to IEC 60068-2-6 · Shocks 11 ms (30 Gn) conforming to IEC 60068-2-27 |
| Ambient air temperature for operation | -20…50 °C |
| Unit Type of Package 2 | S04 |
| Number of Units in Package 2 | 6 |
| Package 2 Height | 30.000 cm |
| Package 2 Width | 40.000 cm |
| Package 2 Length | 60.000 cm |
