Schneider Electric Acti9 iSW switch disconnector, rated 20 A. switch Acti9 iSW - 2 poles - 20 A - 415V.
switch Acti9 iSW - 2 poles - 20 A - 415V. Genuine Schneider Electric product supplied by United Force.
| Range | Acti9 |
|---|---|
| Product name | Acti9 iSW |
| Product or component type | Switch disconnector |
| Device short name | iSW |
| Device application | Control |
| Poles description | 2P |
| Utilisation category | AC-22A |
| Suitability for isolation | Yes |
| [Ie] rated operational current | 20 A at 415 V AC 50/60 Hz |
| [Ue] rated operational voltage | 415 V AC 50/60 Hz |
| [Ui] rated insulation voltage | 500 V AC 50/60 Hz conforming to EN/IEC 60669-2-4 |
| [Uimp] rated impulse withstand voltage | 4 kV |
| Control type | Toggle |
| Local signalling | ON/OFF indication |
| Contact position indicator | Yes |
| Mounting mode | Fixed |
| Mounting support | DIN rail |
| 9 mm pitches | 2 |
| Height | 77 mm |
| Width | 18 mm |
| Depth | 70 mm |
| Colour | White |
| Mechanical durability | 300000 cycles |
| Electrical durability | 30000 cycles |
| Connections - terminals | Tunnel type terminals - 10 mm² - rigid · Tunnel type terminals - 10 mm² - flexible · Tunnel type terminals - 10 mm² - flexible with ferrule |
| Wire stripping length | 9 mm |
| Tightening torque | 1.2 N.m |
| Standards | EN/IEC 60669-2-4 |
| IP degree of protection | IP40 |
| Pollution degree | 2 |
| Tropicalisation | 2 |
| Relative humidity | 95 % at 55 °C |
| Ambient air temperature for operation | -20…50 °C |
| Ambient air temperature for storage | -40…70 °C |
| Unit Type of Package 2 | BB1 |
| Number of Units in Package 2 | 12 |
| Package 2 Height | 8.3 cm |
| Package 2 Width | 9.3 cm |
| Package 2 Length | 22.2 cm |
| Package 2 Weight | 842 g |
| Unit Type of Package 3 | S03 |
| Number of Units in Package 3 | 144 |
| Package 3 Height | 30 cm |
| Package 3 Width | 30 cm |
| Package 3 Length | 40 cm |
