Schneider Electric TeSys VARIO switch body, rated 8.1 A. Switch body,TeSys Control,3 poles,12A,compact size.
Switch body,TeSys Control,3 poles,12A,compact size. Genuine Schneider Electric product supplied by United Force.
| Range | TeSys |
|---|---|
| Product name | TeSys VARIO |
| Product or component type | Switch body |
| Performance level | Standard |
| Poles description | 3P |
| Contacts type and composition | 3 NO |
| Network type | DC · AC |
| Network frequency | 50/60 Hz |
| Mounting support | Symmetrical rail |
| [Ue] rated operational voltage | 690 V AC 50/60 Hz |
| [Uimp] rated impulse withstand voltage | 6 kV |
| [Ith] conventional free air thermal current | 12 A |
| [Ithe] conventional enclosed thermal current | 10 A |
| [Ie] rated operational current | 8.1 A (AC-23) at 400 V |
| Rated operational power in W | 3 kW at 400...415 V (AC-3) · 4 kW at 500 V (AC-3) · 4 kW at 690 V (AC-3) · 1.5 kW at 230...240 V (AC-3) · 5.5 kW at 500 V (AC-23A) · 7.5 kW at 690 V (AC-23A) · 3 kW at 230...240 V (AC-23A) · 4 kW at 400...415 V (AC-23A) |
| Intermittent duty class | 30 |
| Making capacity ( I Rms) | 120 A at 400 V AC-21A · 120 A at 400 V AC-22A · 120 A at 400 V AC-23A |
| [Icm] rated short-circuit making capacity | 0.5 kA at 400 V at Ipeak |
| [Icw] rated short-time withstand Rms current | 140 A at 400 V duration: 1 s |
| Rated conditional short-circuit current | 6 kA at 400 V - associated fuse 12 A aM · 6 kA at 400 V - associated fuse 12 A gG |
| Breaking capacity | 120 A at 400 V (AC-22A) · 120 A at 400 V (AC-23A) · 120 A at 400 V (AC-21A) |
| Mechanical durability | 50000 cycles |
| Electrical durability | 30000 cycles DC-1...5 · 50000 cycles AC-21 |
| Suitability for isolation | Yes |
| Connections - terminals | Power circuit: screw clamp terminals4 mm² - solid · Power circuit: screw clamp terminals4 mm² - flexible - with cable end |
| Tightening torque | Power circuit: 7 N.m - on screw clamp terminals |
| Height | 46.5 mm |
| Width | 56 mm |
| Depth | 62 mm |
| Product weight | 0.11 kg |
| Standards | IEC 60947-3 |
| Product certifications | UL · CSA · GL · UKCA |
| Protective treatment | TC |
| IP degree of protection | IP20 conforming to IEC 60529 |
| Mechanical robustness | Vibrations 10...150 Hz (5 gn) conforming to IEC 60068-2-6 · Shocks 11 ms (15 gn) conforming to IEC 60068-2-27 |
| Ambient air temperature for operation | -20…50 °C |
| Fire resistance | 960 °C conforming to IEC 60695-2-1 |
| Unit Type of Package 2 | S03 |
| Number of Units in Package 2 | 24 |
| Package 2 Height | 30.000 cm |
| Package 2 Width | 30.000 cm |
| Package 2 Length | 40.000 cm |
| Package 2 Weight | 3.328 kg |
| Unit Type of Package 3 | P06 |
| Number of Units in Package 3 | 192 |
