Schneider Electric ComPacT INS switch disconnector, rated 22A. switch disconnector, Compact INS250-200, 200A, standard version with black rotary handle, 3 poles.
switch disconnector, Compact INS250-200, 200A, standard version with black rotary handle, 3 poles. Genuine Schneider Electric product supplied by United Force.
| Range | ComPact |
|---|---|
| Product or component type | Switch disconnector |
| Product name | ComPacT INS |
| Poles description | 3P |
| Network type | DC · AC |
| Network frequency | 50/60 Hz |
| [Ie] rated operational current | AC-22A: 200 A AC 50/60 Hz 220/240 V · AC-22A: 200 A AC 50/60 Hz 380/415 V · AC-22A: 200 A AC 50/60 Hz 440/480 V · AC-22A: 200 A AC 50/60 Hz 480 V NEMA · AC-22A: 200 A AC 50/60 Hz 500/525 V · AC-22A: 200 A AC 50/60 Hz 660/690 V · AC-23A: 200 A AC 50/60 Hz 220/240 V · AC-23A: 200 A AC 50/60 Hz 380/415 V · AC-23A: 200 A AC 50/60 Hz 440/480 V · AC-23A: 200 A AC 50/60 Hz 480 V NEMA · AC-23A: 200 A AC 50/60 Hz 500/525 V · AC-23A: 200 A AC 50/60 Hz 660/690 V · DC-22A: 200 A DC 125 V 2 poles in series · DC-23A: 200 A DC 125 V 2 poles in series |
| [Ui] rated insulation voltage | 800 V AC 50/60 Hz |
| [Ith] conventional free air thermal current | 200 A at 60 °C |
| [Icm] rated short-circuit making capacity | 30 kA switch-disconnector alone 690 V AC at 50/60 Hz · 330 kA with upstream protection circuit breaker 690 V AC at 50/60 Hz |
| [Ue] rated operational voltage | 125 V DC · 690 V AC 50/60 Hz |
| Suitability for isolation | Yes |
| Contact position indicator | Yes |
| Visible break | No |
| Pollution degree | 3 |
| Control type | Direct front rotary handle |
| Handle colour | Black |
| Mounting mode | Fixed |
| Mounting support | Plate · Rail |
| Upside connection | Front |
| Downside connection | Front |
| Maximum power | AC-23: 110 kW at 440 V AC 50/60 Hz · AC-23: 110 kW at 480 V AC 50/60 Hz (NEMA) · AC-23: 132 kW at 500/525 V AC 50/60 Hz · AC-23: 160 kW at 660/690 V AC 50/60 Hz · AC-23: 55 kW at 220/240 V AC 50/60 Hz · AC-23: 55 kW at 230 V AC 50/60 Hz (NEMA) · AC-23: 90 kW at 380/415 V AC 50/60 Hz |
| Rated duty | Uninterrupted |
| [Icw] rated short-time withstand current | 1.8 kA during 30 s conforming to IEC 60947-3 · 2.2 kA during 20 s conforming to IEC 60947-3 · 4.9 kA during 3 s conforming to IEC 60947-3 · 8.5 kA during 1 s conforming to IEC 60947-3 |
| Mechanical durability | 15000 cycles |
| Electrical durability | AC-22A: 1500 cycles 440 V AC 50/60 Hz · AC-22A: 1500 cycles 500 V AC 50/60 Hz · AC-22A: 1500 cycles 690 V AC 50/60 Hz · AC-23A: 1500 cycles 440 V AC 50/60 Hz · AC-23A: 1500 cycles 500 V AC 50/60 Hz · AC-23A: 1500 cycles 690 V AC 50/60 Hz · DC-22A: 1500 cycles 125 V DC 2 poles in series · DC-23A: 1500 cycles 125 V DC 2 poles in series |
| Connection pitch | 35 mm |
| Height | 136 mm |
| Width | 140 mm |
| Depth | 96 mm |
| Product weight | 2 kg |
| Standards | IEC 60947-1 · IEC 60947-3 |
| Product certifications | CCC · KEMA-KEUR |
| IP degree of protection | IP40 conforming to IEC 60529 |
| IK degree of protection | IK07 conforming to EN 50102 |
| Ambient air temperature for operation | -25…70 °C |
| Ambient air temperature for storage | -50…85 °C |
| Unit Type of Package 2 | S04 |
| Number of Units in Package 2 | 9 |
| Package 2 Height | 30.000 cm |
| Package 2 Width | 40.000 cm |
| Package 2 Length | 60.000 cm |
| Package 2 Weight | 20.673 kg |
| Warranty (in months) | 18 |
