Schneider Electric EasyPact CVS switch disconnector, rated 22A. switch disconnector, EasyPact CVS630NA, 3 poles, 630A AC22A, 500A AC23A.
switch disconnector, EasyPact CVS630NA, 3 poles, 630A AC22A, 500A AC23A. Genuine Schneider Electric product supplied by United Force.
| Range of product | EasyPact CVS400...630 |
|---|---|
| Range | EasyPact |
| Product name | EasyPact CVS |
| Device short name | CVS630NA |
| Product or component type | Switch disconnector |
| Device application | Distribution |
| Poles description | 3P |
| Network type | AC |
| [Ie] rated operational current | AC-22A: 630 A AC 50/60 Hz 220/240 V · AC-22A: 630 A AC 50/60 Hz 380/415 V · AC-22A: 630 A AC 50/60 Hz 440 V · AC-23A: 500 A AC 50/60 Hz 220/240 V · AC-23A: 500 A AC 50/60 Hz 380/415 V · AC-23A: 500 A AC 50/60 Hz 440 V |
| [Ith] conventional free air thermal current | 600 A at 50 °C |
| [Icm] rated short-circuit making capacity | 105 kA with upstream protection circuit breaker · 8.5 kA switch-disconnector alone |
| Breaking capacity code | NA |
| Suitability for isolation | Yes conforming to EN 60947-3 · Yes conforming to IEC 60947-3 |
| Utilisation category | AC-22A · AC-23A |
| Earth-leakage protection | Without |
| Network frequency | 50/60 Hz |
| Control type | Toggle |
| Mounting mode | Fixed |
| Mounting support | Backplate |
| Upside connection | Front |
| Downside connection | Front |
| [Icw] rated short-time withstand current | 6 kA during 1 s conforming to IEC 60947-3 · 6 kA during 3 s conforming to IEC 60947-3 · 2.32 kA during 20 s conforming to IEC 60947-3 |
| Contact position indicator | Yes |
| Visible break | No |
| Mechanical durability | 15000 cycles conforming to IEC 60947-3 |
| Electrical durability | AC-22A: 2500 cycles 415 V AC 50/60 Hz In conforming to IEC 60947-3 · AC-23A: 2500 cycles 415 V AC 50/60 Hz In conforming to IEC 60947-3 |
| Connection pitch | 45 mm |
| Height | 255 mm |
| Width | 140 mm |
| Depth | 110 mm |
| Product weight | 6.2 kg |
| Standards | IEC 60947-3 · EN 60947-3 |
| Product certifications | IEC · GOST |
| Electrical shock protection class | Class II |
| Pollution degree | 3 conforming to IEC 60664-1 |
| Ambient air temperature for operation | -25…70 °C |
| Ambient air temperature for storage | -50…85 °C |
| Unit Type of Package 2 | S04 |
| Number of Units in Package 2 | 3 |
| Package 2 Height | 30.000 cm |
| Package 2 Width | 40.000 cm |
| Package 2 Length | 60.000 cm |
| Package 2 Weight | 16.885 kg |
| Warranty (in months) | 18 |
