Schneider Electric TeSys DF fuse carrier, rated 32 A. Fuse carrier, TeSys DF, 3P+N, 32A, 690VAC, fuse size 10x38mm.
Fuse carrier, TeSys DF, 3P+N, 32A, 690VAC, fuse size 10x38mm. Genuine Schneider Electric product supplied by United Force.
| Range | TeSys |
|---|---|
| Product name | TeSys DF |
| Product or component type | Fuse carrier |
| Device short name | DF10 |
| Device composition | tubular link for locked in Neutral pole |
| Product compatibility | DF2CA fuse cartridge · DF2CN fuse cartridge |
| Poles description | 3P + N |
| Fuse size | 10 x 38 mm |
| Fuse type | 0…32 A, gG · 0…32 A, aM |
| Control type | Toggle padlockable |
| Utilisation category | AC-20B conforming to IEC 60947-3 · DC-20B conforming to IEC 60947-3 |
| [Ue] rated operational voltage | 690 V AC · 690 V DC |
| [Ie] rated operational current | 32 A at 400 V AC |
| [Ith] conventional free air thermal current | 32 A 20 °C |
| [Ui] rated insulation voltage | 690 V AC |
| [Uimp] rated impulse withstand voltage | 6 kV |
| Overvoltage category | III |
| Short-circuit withstand | 120 kA 400 V conforming to IEC 60947-3 · 120 kA 500 V conforming to IEC 60947-3 |
| Power dissipation in W | 3 W maximum power dissipation by fuse |
| Standards | EN/IEC 60947-3 · EN/IEC 60269-2 · UL 4248-1 · CSA C22.2 No 4248-1 · EN 45545-2: R22 HL2 |
| Product certifications | IEC · UL recognized · CSA · CCC · EAC · DNV-GL |
| Mounting support | 35 mm symmetrical DIN rail |
| Mounting position | Vertical (tolerance: +/- 23°) |
| Connections - terminals | Screw clamp terminals 1 cable(s) 1…16 mm²rigid · Screw clamp terminals 2 cable(s) 1…6 mm²rigid · Screw clamp terminals 1 cable(s) 1…16 mm²flexible with or without · Screw clamp terminals 2 cable(s) 1…6 mm²flexible with or without |
| Tightening torque | 2.2 N.m - with screwdriver PZ2 · 2.2 N.m - with screwdriver flat Ø 5.5 mm |
| Height | 79.5 mm |
| Width | 70 mm |
| Depth | 61 mm |
| Product weight | 0.171 kg |
| Quantity per set | Set of 3 |
| Ambient air temperature for storage | -40…70 °C |
| Ambient air temperature for operation | -40…70 °C with derating above 20°C |
| Operating altitude | 0...2000 m |
| IP degree of protection | IP20 |
| Pollution degree | 3 |
| Fire resistance | 960 °C conforming to IEC 60695-2-1 |
| Compatibility code | DF10 |
| Unit Type of Package 2 | BB1 |
| Number of Units in Package 2 | 3 |
| Package 2 Height | 6.500 cm |
| Package 2 Width | 8.500 cm |
| Package 2 Length | 22.000 cm |
| Package 2 Weight | 574.000 g |
| Unit Type of Package 3 | S03 |
| Number of Units in Package 3 | 48 |
