Schneider Electric TeSys operator control unit. Operator control unit, TeSys Tera, 140 mA, RJ45 connection, flush-mounted, backlit LCD.
Operator control unit, TeSys Tera, 140 mA, RJ45 connection, flush-mounted, backlit LCD. Genuine Schneider Electric product supplied by United Force.
| Range | TeSys |
|---|---|
| Device short name | LTMCU |
| Product or component type | Operator control unit |
| Range compatibility | TeSys T LTMR motor controller |
| Display type | Backlit LCD |
| Local signalling | 4 LEDs |
| local control | 10 push-button |
| Device connection | Connection to a LTM R controller, RJ45 connector on rear · Connection to a PC, RJ45 connector on front |
| Supply | Via the controller |
| Maximum supply current | 140 mA |
| Power dissipation | 1 W |
| Standards | UL 60947-4-1A · CSA C22.2 No 60947-4-1 · EN/IEC 61131-2 |
| Product certifications | C-Tick · EAC · CSA · NOM · UL · CE |
| Electromagnetic compatibility | Electrostatic discharge, level 3, 8 kV air, 4 kV contact, conforming to EN/IEC 61000-4-2 · Radiated RF fields, level 3, 10 V/m, conforming to EN/IEC 61000-4-3 · Conducted RF disturbances, level 3, 10 V, conforming to EN/IEC 61000-4-6 · Surges (shielded access), level 3, 2 kV, conforming to EN/IEC 61000-4-5 · Fast transient bursts (shielded access), level 3, 2 kV, conforming to EN/IEC 61000-4-4 |
| IP degree of protection | IP54 (front) conforming to EN/IEC 60947-4-1 · IP20 (rear) conforming to EN/IEC 60947-4-1 |
| Mounting mode | Flush-mounted |
| Width | 117 mm |
| Height | 70 mm |
| Depth | 50 mm |
| Product weight | 0.4 kg |
| Ambient air temperature for operation | -20…60 °C |
| Ambient air temperature for storage | -40…80 °C |
| Relative humidity | 15…95 % |
| Protective treatment | TC 12 humidity cycles at 55 °C conforming to EN/IEC 60068-2-30 |
| Mechanical robustness | Shocks: 15 Gn for 11 ms conforming to EN/IEC 60068-2-27 · Vibrations: 4 Gn, 5...300 Hz conforming to EN/IEC 60068-2-6 |
| Fire resistance | 650 °C conforming to EN/IEC 60947-1 |
| Flame retardance | V2 conforming to UL 94 |
| Unit Type of Package 2 | S03 |
| Number of Units in Package 2 | 32 |
| Package 2 Height | 30.000 cm |
| Package 2 Width | 30.000 cm |
| Package 2 Length | 40.000 cm |
| Package 2 Weight | 9.108 kg |
| Warranty (in months) | 18 |
