Schneider Electric ComPacT trip unit. Trip unit MA220, ComPacT NSX250, 3 poles, magnetic protections, motor protection, 220A rating.
Trip unit MA220, ComPacT NSX250, 3 poles, magnetic protections, motor protection, 220A rating. Genuine Schneider Electric product supplied by United Force.
| Range | ComPacT |
|---|---|
| Range of product | ComPacT NSX100...250 |
| Product or component type | Trip unit |
| Trip unit name | MA |
| Trip unit technology | Magnetic |
| Range compatibility | ComPacT NSX250 |
| Device application | Motor |
| Poles description | 3P |
| Protected poles description | 3D |
| Trip unit protection functions | I |
| Protection type | I : for short-circuit protection (magnetic) |
| Trip unit rating | 220 A at 65 °C |
| [Ue] rated operational voltage | 690 V AC 50/60 Hz |
| Network type | AC |
| Network frequency | 50/60 Hz |
| Circuit breaker mounting mode | Fixed |
| Instantaneous protection pick-up adjustment type Ii | Adjustable |
| [Ii] instantaneous protection pick-up adjustment range | 9...14 x In |
| Earth-leakage protection | Without |
| Standards | EN/IEC 60947-2 |
| Electrical shock protection class | Class II |
| Pollution degree | 3 conforming to IEC 60947-1 |
| IP degree of protection | IP40 conforming to IEC 60529 |
| Ambient air temperature for operation | -25…70 °C |
| Ambient air temperature for storage | -50…85 °C |
| Unit Type of Package 2 | S03 |
| Number of Units in Package 2 | 28 |
| Package 2 Height | 30.000 cm |
| Package 2 Width | 30.000 cm |
| Package 2 Length | 40.000 cm |
| Package 2 Weight | 11.896 kg |
| Warranty (in months) | 18 |
